Multi-Layer Co-Extrusion Biodegradable Material Sheet Unit
SKY WIN Technology Co., Ltd.- Product Type：Plastic Sheet
- Screw：Double-Screw
- Automation：Automatic
- Certification：CE, ISO9001:2008
- Customized：Customized
- Plastic Processed：PLA
Base Info
- Product Thickness：0.2-2mm
- Output：400
- Screw Diameter：72*2,&50*2
- Sheet Width(mm)：≤750
Description
Basic Info.
Product Thickness 0.2-2mm Output 400 Screw Diameter 72*2/&50*2 Sheet Width(mm) ≤750Product Description
Features:
1.Applies to PLA, the full degradation of starch based.
2.Multi-Layer Co-Extrusion sheet production.
3.The machine barrel is made from the same direction twin-screw extruder.
4.Two vacuum vent,water discharge effect is good.
Technical Parameters
Model | Suitable Material | Screw Diameter(MM) | L/D | Sheet Thickness(MM) | Sheet Width(MM) | Max Capacity(KG/H) | Power(KW) |
SWP800 | PLA full degradation of starch based | φ72*2/φ50*2 | 1:48 | 0.2-2 | ≤750 | 400 | 280 |
