Single Screw Mini Film Blowing Machine Screw 45/55/65
WENZHOU HUACHU MACHINERY CO., LTD.- Type：High and Low Pressure Film Blowing Machine
- Raw Material：PE
- Maximum Folding Width of Film：1200mm
- Screw Diameter：65mm
- Automation：Automatic
- Computerized：Computerized
Base Info
- Model NO.：YN-700
- Machine Weight：4T
- Transport Package：Wooden Box
- Specification：20CBM
- Trademark：000
- Origin：Zhejiang
- HS Code：8477301000
- Production Capacity：240
Description
Basic Info.
Model NO. YN-700 Machine Weight 4T Transport Package Wooden Box Specification 20CBM Trademark 000 Origin Zhejiang HS Code 8477301000 Production Capacity 240Product Description
YN-50,55,60,65 PE/LDPE/HDPE/LLDPE FILM BLOWING MACHINETechnology Parameter
| TYPE MODEL | YN-700 | YN-900 | YN-1100 | YN-1350 |
| SCREW DIA. | Φ50 | Φ55 | Φ60 | Φ65 |
| MATERIAL TO BE USED | PE/LDPE/HDPE/LLDPE | PE/LDPE/HDPE/LLDPE | PE/LDPE/HDPE/LLDPE | PE/LDPE/HDPE/LLDPE |
| SCREW RATIO L/D | 30/1 | 30/1 | 30/1 | 30/1 |
| SCREW SPEED | 15-100r/min | 15-100r/min | 15-100r/min | 15-100r/min |
| MAIN MOTOR POWER | 15 KW | 18.5 KW | 22.5 KW | 30 KW |
| MAX.EXTRUSION OUTPUT | 50 kg/h | 60 kg/h | 70 kg/h | 90 kg/h |
| RANGE OF DIE | Φ80Φ100 | Φ100Φ120 | Φ120Φ200 | Φ150Φ220 |
| THICKNESS OF FILM | 0.008-0.10mm | 0.008-0.10mm | 0.01-0.10mm | 0.01-0.10mm |
| MAX FOLDING WIDTH OF FILM | 600mm | 800mm | 1000mm | 1200mm |
| ELECTRIC TOTAL CAPACITY | 24kw | 30kw | 38kw | 46kw |
| DIMENSION(LxWxH)(m) | 3x2.5x4.2 | 3.2x2.8x4.5 | 3.8x3.5x5 | 4.2x3.8x5.2 |
| WEIGHT OF MACHINE | 2.5T | 3.0T | 3.5T | 3.8T |
Welcome to contact us for more details and prices!!!
