Simple PE Film Blowing Machine
Ruian Queensense Machine Co., Ltd.- Type：PE Film Blowing Machine
- Raw Material：PE
- Automation：Automatic
- Computerized：Non-Computerized
- Certification：CE
- Suitable Material：LDPE,LLDPE,HDPE
Base Info
- Model NO.：JY-SJ
- Transport Package：Wooden Box
- Specification：CE
- Trademark：QUEENSENSE
- Origin：China
- HS Code：8477309000
- Production Capacity：30kgsh
Description
Basic Info.
Model NO. JY-SJ Transport Package Wooden Box Specification CE Trademark QUEENSENSE Origin China HS Code 8477309000 Production Capacity 30kgshProduct Description
Characteristics:
This machine set is used for blowing low-density polyethylene(LDPE)and high density polyethylene(HDPE)plastic film to make various vest bags and flat-rim bags which have been widely used for packing in the garment industry, textile industry, and food industry, etc.<o:p>
Main Technical Variables:
| Model | JY-SJ45 |
| Screw Diameter(mm) | 50 |
| Screw L/D | 28:1 |
| Screw Speed | 10-110r/min |
| Blowing film driving motor(kw) | 11 |
| Main Output(kg/hr) | 30 |
| Max. Width of Film(mm) | 600 |
| Single-sided Thickness of Film(mm) | 0.006-0.10 |
| Total Power (kw) | 22 |
| Weight of Machine (kg) | 2200 |
| Overall Dimensions(mm) | 4000*2000*2800 |
