• Model NO.：SJ-A45,70
• Machine Weight：4T
• Certification：CE, ISO9001:2008
• Transport Package：Wooden Case and Stretch Film Package
• Specification：CE,ISO9001
• Trademark：Changyin
• Origin：China
• HS Code：84773000
• Production Capacity：400sets,Year

Basic Info.

Model NO. SJ-A45/70 Machine Weight 4T Certification CE, ISO9001:2008 Transport Package Wooden Case and Stretch Film Package Specification CE/ISO9001 Trademark Changyin Origin China HS Code 84773000 Production Capacity 400sets/Year

Product Description

Uses:
1) SJ-A series HDPE/LDPE film blowing machine is used for blowing various Plastic film of low dentisity polyethylene (LDPE), high dentisty polyethylene (HDPE) and linear low density polyethylene (LLDPE) and so on
2) Which are widely used for packing liquid, industrial products, garments, textile and printing lamination

TECHNICAL DATA:
Technical data:
1. Model: SJ-A50 Film blowing machine
Diameter of screw: 50mm
L/D: 26: 1
Single-face thickness of film: 0.008-0.06mm
Reduced diameter of film: 100-600mm
Max. Output: 25-30kg/h






Power of main motor: 11kw
Power of Traction motor: 1.1kw
Heating power: 13kw
Outline dimension: 5000*2000*4200mm
Weight: 2.5T

2. Model: SJ-A55 Film blowing machine
Diameter of screw: 55mm
L/D: 26: 1
Single-face thickness of film: 0.008-0.06mm
Reduced diameter of film: 200-800mm
Max. Output: 35-40kg/h
Power of main motor: 15kw
Power of Traction motor: 1.1kw
Heating power: 19kw
Outline dimension: 5200*2200*4500mm
Weight: 3.0T

3. Model: SJ-A60 Film blowing machine
Diameter of screw: 60mm
L/D: 26: 1
Single-face thickness of film: 0.008-0.06mm
Max. Output: 60-65kg/h
Reduced diameter of film: 300-1000mm
Power of main motor: 18.5kw
Power of Traction motor: 1.5kw
Heating power: 21kw
Outline dimension: 5500*2500*5200mm
Weight: 3.5T

4. Model: SJ-A70 Film blowing machine
Diameter of screw: 70mm
L/D: 26: 1
Single-face thickness of film: 0.008-0.06mm
Max. Output: 65-70kg/h
Reduced diameter of film: 400-1200mm
Power of main motor: 22kw
Power of Traction motor: 1.5kw
Heating power: 23kw
Outline dimension: 5800*7800*6300mm
Weight: 4.0T
