• Model NO.：20-630mm
• Condition：New
• PP-R Pipe Production Line：20-160mm
• Transport Package：Wooden
• Specification：International
• Trademark：XJG
• Origin：China
• HS Code：8477800000
• Production Capacity：Uncertain

Basic Info.

Model NO. 20-630mm Condition New PP-R Pipe Production Line 20-160mm Transport Package Wooden Specification International Trademark XJG Origin China HS Code 8477800000 Production Capacity Uncertain

Product Description

Machine Characteristics 1. The optimum spiral structure feeding throat highly improves the output of extruder 2. Accurate temperature control system ensures materials melting performance 3. Unique screw design achieves better plasticizing and high quality products 4. Precisely designed gearbox with a high torsion guarantees stable running 5. "H" shape frame to decrease vibrating of extruder 6. Advanced PLC operation system realizes synchronization and automation 7. Adopt automatic water temperature & level control and special independent filters on both vacuum and cooling tanks 8. Offer stable haul-off unit with 2-12 caterpillars 9. Provide saw & chip-free cutting options 10. Low energy consumption, excellent performance, and easy maintenance


Mode	PE75	PE125	PE250	PE630
(MM) Max Diam.	Φ 75	Φ 125	Φ 250	Φ 630
Extruder	SJ65/28--SJ65/30B	SJ90/28--SJ90/30B	SJ90/32---SJ90/32B	SJ120/30B
Power(KW)	40/90	60/132	90/132	280
Motor type	Direct current model	Direct current model	Direct current model	Direct current model
Output(KG/H)	85/210	130/300	300/450	900-1000
Speed(M/MIN)	1.5-10	0.6-6	0.4-4	0.1-1
Max. traction(N)	9800	15000	19500	39000
Cutting type	Disc type cutting	type cutting	Planet model with cut angle funcation	Planet model with cut angle funcation
Measurement(MM)	28000× 35000× 3000	30000× 35000× 3000	38000× 35000× 3500	45000× 35000× 4000
