• Model NO.：LZ-700,1200
• Plastic Vacuum Machine：Plastic Box Vacuum Machine
• Transport Package：Plywood
• Specification：CE
• Trademark：CHINAWORLD
• Origin：Ruian City, Zhejiang Province
• HS Code：84774090
• Production Capacity：5sets,Month

Overview

Product Description

CW-700/1200A Automatic Computerized vacuum forming machine is designed by the principle of mechanical-electrical-pneumatic integration. It adopts PLC control system, panel and digital power control. This full-automatic forming equipment for thermoforming plastic sheet includes feeding, heating, forming, cooling, mold ejecting, cutting and one blow.
Application area:
This machine is mainly applied to plastic sheet material molding, such as EPS, HIPS, PVC, PET, PP and flocking sheet, etc. which produce all kinds of trays, trays for medicine injection, oral liquid, vegetables, telephones, cookies, tool, hardware, electron and disposable tableware, etc.
Main functions:
→Automatic feeding: Large diameter cylinder type automatic material feeding frame. Equipped with coated silicone oil installations. Adopt Taiwan micro-motor drive rubber roller. Fixed gear slider (up and down) improve flexibility and durability.
→Heating: 60 pieces of hot bricks separately controlled by 60 insurance circuit breakers, 60 digital readout voltage regulators, according to the product requirements can adjust the block temperature; Oven, heat insulation adopt Stainless steel built-in insulation cotton, and the sliding insulating aluminum plate with water device
→Molding: Up and down mould delay, The vacuum time delay, small vacuum and secondary vacuum time delay, large vacuum, firstly upper die, secondary upper die delay etc, Multi-function parameters and arbitrary adjustment, setting of action; Greatly improve the quality of the finished product and molding rate.
→Cooling: Cooling delay, cooling time, Water spray delay, spray time, adjust the length of the time according to different products.
→Demould: It can adjust the size of bottom blowing, according to the length of time; Another is equipped with vibration demould, can be arbitrary adjust the wave frequency and amplitude, in view of the complex products difficult demoulding and setting.
→Traction to send sheet: Use the high power, 2.2 KW Traction to send sheet:  Adopt  Taiwan decelerating motor, 2.2kw schneider inverter to increase pull strength (former 1.5 KW);  Import the encoder and the Man-machine interface pulse to control the precision and speed of feeding sheet; in addition, it can set time control the sheet length for standby.
→Cutting the sheet: Using the reinforcement tablet arm type cutting, avoid wafer cutting skid.
→Put slices into the container: Adopt gear structure improve the smooth and durability
The machine (in addition to the heating device and motor) all action adopts dc 24 v low voltage control, in order to improve operation safety

Product Parameters

Main technical parameters:Model:LZ-700/1200A-1LZ-700/1200A-2Forming length760-1200mm760-1200mmForming width500-700mm500-700mmForming height<165mm<165mmProduction speed60-720cycle/h60-720cycle/hElectro-thermal furnace power24kw24kw( upper)
18kw(lower)Vacuum motor power3kw3kwPumping rate100m³/h100m³/hAir compressor power7.5kw-11kw7.5kw-11kwAir displacement1.2m³/min1.2m³/minVoltage380/220V, 50Hz380/220V 50HzOverall dimensions7950×1450×2550mm7950×1450×2550mmWeight3000kg3500kg
