Plastic Machinery

Fg-8 Blow Molding Machine

Jiangsu Faygo Union Machinery Co., Ltd.
  • Type:Stretch Blow Molding Machine
  • Raw Material:PET
  • Making Method of Parison:Stretch Blow
  • Automation:Automatic
  • Computerized:Computerized
  • Certification:CE, ISO9001:2008, QS, UL, GMP

Base Info

  • Model NO.:FG-8
  • Capacity:12000~13000bph
  • Material:Pet
  • Motor:Servo
  • PLC:Siemens
  • Bottle Volume:250ml~750ml
  • Transport Package:PP,PE Film
  • Specification:CE&ISO9001~2000
  • Trademark:Faygo Plast
  • Origin:Jiangsu Zhangjiagang
  • HS Code:8448900
  • Production Capacity:12000~13000bph

Description

Main PartsPneumatic part& CylinderValveGERMAN Electric partPLCJAPAN MitsubishiServo SystemJAPAN PanasonicFrequency inverterJAPAN MitsubishiOperating systemJAPAN MitsubishiTouch screenJAPAN MitsubishiBlowingValveJAPAN ParkerOne-way ValveGERMAN Throttle ValveGERMAN Reducing ValveGERMAN DURAYNoteAll of the electrical components adopts CE,UL,CCC approved international advanced high-tech productMain ParameterModelFG-4CapacityDepend on bottle design6800-7200PCS/HApplicable PreformHeight<330mmNeck20mm-25mmApplicable BottleNeck20-25mmVolumeMax.2LiterHeightMax.328mmDiameterMax.105mmElectric consumptionInstall power51kw 380v 3Phase /220v 3Phase  50/60HZHeating oven powder46kwHeating Oven operating power26kwAir consumptionPressure4m3/min 4.0MPa Capacity4m3/min 4.0MPa Mold ChillerPressure4-6BarTemperature6-13ºCFlow45L/minOven ChillerPressure4-6BarTemperature6-13ºCFlow26L/minMachine DimensionL*W*H3900*900*2500mmWeight3500kgFg-8 Blow Molding MachineFg-8 Blow Molding MachineFg-8 Blow Molding MachineFg-8 Blow Molding Machine
