EVA PE Rubber Foaming Machine
Qingdao Eenor Rubber Machinery Co., Ltd.- Type：EVA Foam Machine
- Raw Material：EVA
- Principle：EVA Foam
- Automation：Automatic
- Computerized：Non-Computerized
- Certification：Ce, ISO
Base Info
- Model NO.：XLB-Q1200x1200x6,6.00MN
- Usage：EVA Foaming Machine
- Type of General Rubber Machinery：Laminating Machine
- Transport Package：Wooden Box
- Specification：CE ISO9001
- Trademark：eenor
- Origin：China
- HS Code：84778000
- Production Capacity：600 Sets,Year
Description
Basic Info.
Model NO. XLB-Q1200x1200x6/6.00MN Usage EVA Foaming Machine Type of General Rubber Machinery Laminating Machine Transport Package Wooden Box Specification CE ISO9001 Trademark eenor Origin China HS Code 84778000 Production Capacity 600 Sets/YearProduct Description
Features of EVA/PE/rubber foaming machine*High rigidity, low deformation.
*Excellent pressure maintaining. High back pressure retaining.
*Fast open mould.
*Pressure relief when opening mould satisfy the technical needs for high, middle and low level products.
*Platen is special designed, which make temperature even on the platen.
XLB-Q1200x1200x6/6.00MN hydraulic press
1. Total pressure: 6.00MN
2. Plate size: 1200X1200X70mm
3. Plate clearance: 150mm
4. Working layer: 6
5. Piston stroke: 900mm
6. Diameter of piston: 650mm
7. Number of piston: 1 sets
8. Plate pressure: 42kgs/cm2
9. Motor power: 22.5 Kw
10. Dimension: 1850*1200*4100
11. Weight: Approx 26 tons
12. Configuration: 4-pillars
13. Closing speed: >=12mm/s
14. Opening time: <5s
| TYPE | XLB-Q1200*1200*6/6MN |
| TOTAL PRESSURE | 6 MN |
| PLATE SIZE | 1200*1200*70MM |
| PLATE CLEARNACE | 150MM |
| WORKING LAYER | 6 |
| PISTON STROKE | 900MM |
| DIAMETER OF PISTON | 650MM |
| NUMBER OF PISTON | 1 |
| PLATE PRESSURE | 42KGS/CM² |
| MOTOR POWDER | 22.5 kw |
| DIMENSION | 1850*1200*4100mm |
| WEIGHT | 26T |
| CONFIGURATION | 4- pillar |
| CLOSING SPEED | >=12mm/s |
| OPENING TIME | <5s |
