PP/PE/PS/Abssingle Layer /Multi-Layer Sheet/Plate Extrusion Line (SJ90)

Qingdao Leader Machinery Co., Ltd.
  • Product Type：PE Board
  • Board Layers：Multilayer
  • Automation：Automatic
  • Computerized：Computerized
  • Certification：CE, ISO9001:2008
  • Max Capacity：800kgs

Base Info

  • Model NO.：SJ65,30, 90,30, 120,30, 150,30
  • Installed Power：100kw
  • Transport Package：Wooden Case or Other Moistureproof Packages
  • Specification：ISO9001-2000
  • Trademark：LEADER
  • Origin：Qingdao China
  • HS Code：8477209000
  • Production Capacity：100set,Year

Description

Basic Info.

Model NO. SJ65/30, 90/30, 120/30, 150/30 Installed Power 100kw Transport Package Wooden Case or Other Moistureproof Packages Specification ISO9001-2000 Trademark LEADER Origin Qingdao China HS Code 8477209000 Production Capacity 100set/Year

Product Description

PP/PE/PS/Abssingle Layer /Multi-Layer Sheet/Plate Extrusion Line (SJ90)
This line is specially used for producing PP/PE/PS/ABS single layer or multi-layer sheet or plate, suitable in the fields of packaging, stationery, chemicals, construction, household appliances and so on.

PP/PE/PS/Abssingle Layer /Multi-Layer Sheet/Plate Extrusion Line (SJ90)
PP/PE/PS/Abssingle Layer /Multi-Layer Sheet/Plate Extrusion Line (SJ90)
PP/PE/PS/Abssingle Layer /Multi-Layer Sheet/Plate Extrusion Line (SJ90)
Main technical data:

1. Usual sheet width:
700, 900, 1020, 1200, 1300, 1400, 1500, 1700, 1800, 2100, 2200mm

2. Usual Sheet thickness
: 0.5-2mm, 1.5-10mm, 6-20mm, 3-30mm

3. Extruder: Special screw structure, imported world-known thermocontrollers, electronics, hard gear face reducers to ensure high effective material extrusion capacity.

4. T -type die head:
Suitable compression ratio to ensure uniform flow stability.

5.Three-roller calendar:
According to the material properties, adopting vertical three-roller, oblique three-roller, horizontal three-roller calendar. Internal roller temperature control using a unique flow channel, so that the stability of uniform distribution roller. The independent oil temperature control for three roller to ensure more stable and exact control.

6. Cooling frame: According to product specifications, configurations with different specifications of the stainless steel cooling roller

7. Edge-cutting devices: Trimming can be divided into manual and automatic, three-dimensional configuration tool adjustment device, width adjustable.

8.Cut off machine: Saw cutting or knife cutting, thin type and non-friable type sheet generally usually knife cut, adopted high-quality alloy cutting tools, sharp and durable.
