Rbt-Robot for Stacking Cups/Lids/Plastes (Thermoforming Machine)

Ruian Hoin Machinery Co., Ltd.
  • After-sales Service：Technical Support Online
  • Warranty：One Year
  • Column number：10 Rows
  • Molding Method：Extrusion
  • Automatic Grade：Semiautomatic
  • Transport Package：Film Packaging

Base Info

  • Model NO.：RBT
  • Specification：4m*1.4m*1.2m
  • Trademark：HOIN
  • Origin：Ruian,Wenzhou,China
  • Production Capacity：10sets,Months

Description

Basic Info.

Model NO. RBT Specification 4m*1.4m*1.2m Trademark HOIN Origin Ruian/Wenzhou/China Production Capacity 10sets/Months

Product Description

Robot Stacking Machine
A.SPECIFICATION
The machine can connect with the thermoforming machine to stack cups.
B.MAIN TECHNICAL PARAMETER
Machine function:For Stacking Cups
TypeServo Motor
Vertical stroke1400mm
Crosswise Stroke750mm
Max load (with tool)3Kg
Minimum Take Time 0.7 Sec
Dry Cycle Time(without tool)1.7 Sec
Drive SystemPneumatic
Working Air Pressure0.5Mpa
Ower Consumption1.8KVA
Conveyer Table(L*W)3.5m*0.9
PowerAc 220V   50/60HZ
Net Weight350kg
C.MACHINE DETAILS Rbt-Robot for Stacking Cups/Lids/Plastes (Thermoforming Machine)Robot Stacking Machine And Thermoforming Machine
Rbt-Robot for Stacking Cups/Lids/Plastes (Thermoforming Machine)D.MORE PRODUCTS
1.Plastic Sheet Extruder(Single Screw/Double Layers)
2.Plastic Thermoforming Machine(Cup/Lid/Bowl/Tray/Container Making Machine,etc...)
3.Thermoforming Moulds(Cup/Lid/Bowl/Tray/Container Mould,etc...)
4.Plastic Cup Printing Machine & Cup Packing Machine & Cup Stacking Machine
5.Film Blowing Machine & Flim Printing Machine & Bag Making Machine
6.Other Auxiliary Equipments:Mixing Machine,Material Feeding Machine,Cooling Tower,
   Robot,Cup Stacking Machine,Hydraulic Forlift,Chiller,Crushing Machine,etc...
