• Model NO.：PB-CM
• Brand Name：Pym
• Base Material：38crmoaia,42CrMo
• Place of Origin：Zhejiang China
• Delivery：25 Dyas
• Warranty：12 Months
• Transport Package：Stardand
• Specification：CE SGS BV TUV
• Trademark：PYM
• Origin：Zhejiang Ruian
• HS Code：847790000
• Production Capacity：135kg,Hr

Basic Info.

Model NO. PB-CM Brand Name Pym Base Material 38crmoaia,42CrMo Place of Origin Zhejiang China Delivery 25 Dyas Warranty 12 Months Transport Package Stardand Specification CE SGS BV TUV Trademark PYM Origin Zhejiang Ruian HS Code 847790000 Production Capacity 135kg/Hr

Product Description

Latest Design Plastic Crushing Machines
Features of strong granulators(claw cutter):
Suitable for recycle and restore of all kinds of plastics, particularly for various hard plastics, e. G. Blow molded products and shoe last.
1. Easy to operate, low electricity consumption & durable.

2. Uses Japan's high quality steel material especially for making cutter of the crushers, .
3. The blades can be grinded for many times and can be used repeatedly
4. Easy to clean and maintain; The hopper, crusher room, blades and screen can be removed and installed easily.
5. Brand Motor and SCHNEIDER ELECTRIC with Over-loading protection
6. Double wall hoopper designed, low noise.


Configuration of plastic crusher:

1. Electrical appliance: Taiwan (GuanHua)motor, and Chint and SchneiderElectric.

2. Depending on the material matching the different tool materials: 9SiCr(alloy steel), SKD-11, chromium molybdenum vanadium.

3. Mesh material: High carbon steel plate thickness of 5mm(diameter4-8mm). 4. Bearing: NSK bearings imported from Japan.

Model	cir cumgyrate blade size(MM)	outside dimension(MM)	cir cumgyrate blade rotate speed(R/MIN)	sieve hole dia(MM)	fragmentation power(KG/N)	power(KW)	weight(KG)
CF-B-300	300	1110*720*1130	560	8	100-250	5.5	400
CF-B-400	400	1200*850*1280	560	10	200-450	7.5	580
CF-B-500	500	1300*1000*1520	560	10	360-720	11	800
CF-B-600	600	1500*1150*1750	560	10	450-800	15	980
CF-B-800	800	2000*1250*2100	560	12	800-1000	22-30	1800
