Double-Layer PE Coextrusion Film Blowing Machine
Ruian Queensense Machine Co., Ltd.- Type:Rotary Die Ilm Blowing Machine
- Raw Material:HDPE
- Maximum Folding Width of Film:2000mm
- Screw Diameter:65mm
- Automation:Automatic
- Computerized:Computerized
Base Info
- Model NO.:QS-2G50,55,60
- Machine Weight:4T
- Certification:CE, ISO9001:2008, QS
- Film Thickness:0.028-0.2mm
- Max.Extrusion Output:180kg,H
- Driving Motor:18.5-30kw
- Winding Speed:5-50m,Min
- Size:5.6*2.8*5.5m
- Transport Package:Seaworthy
- Specification:CE SGS
- Trademark:QUEENSENSE
- Origin:China
- HS Code:847780000
- Production Capacity:1000PCS,Per Years
Description
Basic Info.
Model NO. QS-2G50/55/60 Machine Weight 4T Certification CE, ISO9001:2008, QS Film Thickness 0.028-0.2mm Max.Extrusion Output 180kg/H Driving Motor 18.5-30kw Winding Speed 5-50m/Min Size 5.6*2.8*5.5m Transport Package Seaworthy Specification CE SGS Trademark QUEENSENSE Origin China HS Code 847780000 Production Capacity 1000PCS/Per YearsProduct Description
This machine is applied to manufacturing printed or uncolored T-shirt bags made of HDPE, LDPE roll film. It adopts double stepping (servo) motor fixed length, and the feeding, sealing, cutting, punching holes and transporting are completed only in one process. It is of high degree of automation and good economic results.
Model | QS-2G50 | QS-2G55 | QS-2G60 |
Diameter of screw | 50× 2 | 55× 2 | 60× 2 |
L/D | 28: 1 | 28: 1 | 28: 1 |
Reduced diameter of film(mm) | 800 | 1000 | 1200 |
Single-face Thickness of film(mm) | 0.015-0.10 | 0.015-0.10 | 0.015-0.10 |
Max. Output(kg/h) | 40 | 65 | 80 |
Power of main motor(kw) | 11× 2 | 15× 2 | 18.5× 2 |
Heating Power(kw) | 26 | 30 | 42 |
Outline diameter(L× W× H)(mm) | 4200× 2200× 4000 | 4600× 2400× 4600 | 5000× 2800× 5000 |
Weight(T) | 4 | 5 | 6 |
