• Model NO.：XY-8
• Capacity：3-10tons,Day
• Size of Reactor：2200*6000; 2600*6600mm
• Material of Reactor：Q245r Boiler Steel
• Structure Form：Horizontal
• Material：Tyre, Plastic, Rubber, etc
• Fule：Wood, Coal, Natural Gas, Fule Oil
• Oil Output(Tyre for Example)：40%~45%
• Powerl：10-15kw
• Totall Weight：25-32tons
• Transport Package：Containers
• Specification：CE, ISO, SGS
• Trademark：JINYUAN
• Origin：Henan, China
• HS Code：8419409090
• Production Capacity：80sets Per Month

Basic Info.

Model NO. XY-8 Capacity 3-10tons/Day Size of Reactor 2200*6000; 2600*6600mm Material of Reactor Q245r Boiler Steel Structure Form Horizontal Material Tyre, Plastic, Rubber, etc Fule Wood, Coal, Natural Gas, Fule Oil Oil Output(Tyre for Example) 40%~45% Powerl 10-15kw Totall Weight 25-32tons Transport Package Containers Specification CE, ISO, SGS Trademark JINYUAN Origin Henan, China HS Code 8419409090 Production Capacity 80sets Per Month

Product Description

1) Raw material:
Waste tyre, used rubber, waste plastic

2)Output:
Crude oil, carbon black, steel wire, waste gas

3) Fuel
The fuel can be fuel oil, heavy oil, coal& firewood.

4) End product percentage (the raw material is tyre)

Fuel oil Carbon black Steel wire Waste gas
45% 35% 10-12% 8%-10%

5) The machine installation
We will give the foundation drawings to buyer after make the order. We will send engineer when buyer gets the machine. The engineer mainly installs the machine and trains your workers.

6) The machine covers area:
The machine itself cover 300 square meters (length 20M, Width 15M)
Add raw material stay, carbon black stay, big oil tank zone, workers rest room and simple office. It takes at least 600-800 square meters.

7) Workers need to operate machine:
Two workers are enough for one set machine.

8) Delivery time:
We will delivery the machine within 15-20days after get the advance payment (30% of the total amount).
Packaging and Shipping


Packaging details	1*40FR and 1*40HQ for 10 tons 2*40 HQ for 5 tons Weight of Reactor: about 30tons All goods are packed with export standard package to make sure no damage during transportation.
Detail details	Within 30 days after receiving deposit.

9) Port (China):
Lianyungang port or Qingdao port

10) Working process:
Firstly, two or three workers put the raw material into the furnace, seal the feed inlet, and then burn the coal /wood in the bottom of the furnace, or it can be heated by electricity directly. The waste raw material in the reactor will be heated slowly. The oil steam will be produced when the temperature reach 180° C-400° C. And then the oil steam will be separate to light component and heavy component by separate device. The light component will enter into the condenser and meanwhile the residues will be discharged automatically in succession. After cooling, the liquefied part will be crude oil, and the waste gas (this part can not be liquefied) will return to heating supply system to be burned by combustion gas purification system.

11) The end tire product and usage
Tyre oil is also called fuel oil, and can be sold directly. (They are also used for deep processing or used for boiler fuel, bath center, restaurant, burn floor brisk and so on ) or use refining equipment to further processing.

12) Warranty and after-service:

A. Quality warranty period: One year warranty for the main reactor of pyrolysis machines and Lifetime maintenance for complete set of machines. <o: P>
B. Our company sends engineers for installation and commissioning in buyer's site including the training of skills of buyer's workers on operation, maintenance, etc.

13). Have exported to many countries:

We have been exported to USA, Saudi Arabia, New Zealand, Australia, Poland, Malaysia, India, Pakistan, Thailand, Vietnam, Indonesia, South Africa, Korea, Bangladesh, etc.
