Plastic Machinery

Home > Product > Film Blowing Machine

Mini Type Film Blowing Machine

WENZHOU HUACHU MACHINERY CO., LTD.
  • Type：Single-Layer Co-extrusion Film Blowing Machine
  • Raw Material：HDPE
  • Maximum Folding Width of Film：600mm
  • Screw Diameter：45mm
  • Automation：Automatic
  • Computerized：Computerized

Base Info

  • Model NO.：YN-HM45B-700
  • Machine Weight：4T
  • Certification：QS
  • Transport Package：Wooden Box
  • Specification：8CBM
  • Trademark：wenzhou brother union
  • Origin：Ruian
  • HS Code：8477301000
  • Production Capacity：20sets,Montth

Description

                   SACM-645 STEEL WITH
HARDENED & NITROGEN TREATMENTCYLINDER MATERIALCYLINDER COOLING1/4 HP x3DRIVING MOTOR20 HPHEATER CAPACITY10 KWDIES (mm)Φ60/80CONTROL PANEL TYPEATTACHED TYPE SWITCH BOARDTEMPERATURE CONTROL4 POINTSCOOLING TYPEAIR COOLING TYPEAIR BLOWER2 HP + INVERTERTAKE-UP TYPEADJUSTABLEPINCH ROLLER (mm)Φ165 x700 LTAKE-UP MOTOR2 HP + INVERTERTAKE-UP SPEED (m/min)9-90WINDING UNIT TYPEATTACHED MANUAL WINDEREFFECTIVE WIDTH600mmFILM WIND-UP ROLL DIA.Φ700 mmWINDING MOTOR2 HP + INVERTERDIMENSION(LxWxH)(m)2.5x1.8x3.5OPTIONAL DEVICESAUTO HOPPER LOADER,
ROTATY DIE DEVICE,
EMBOSSING ROLLER, AIR SHAFT,
CORONA SURFACE TREATER
Mini Type Film Blowing Machine

Mini Type Film Blowing Machine
Mini Type Film Blowing Machine
