• Model NO.：HJ80
• Clamping Way：Hydraulic & Mechanical
• Automation：Automatic
• Computerized：Computerized
• Certification：CE, ISO9001:2008
• Transport Package：Wooden Box Package
• Specification：CE
• Trademark：HAIJIA
• Origin：Zhejiang Ningbo
• HS Code：8477101090
• Production Capacity：3000 PCS,Year

      Model
 Units
 HJF-400

Injection system
 Screw Diameter
 mm
 32
 36
 Injection Pressure
 Kg/cm2
 1662
 1313
 Theoretical Shot Volume
 cm3
 96
 122
 Max. Shot Weight(P.S)
 g/Oz
 86/3.0
 109/3.8
 Injection Rate
 cm3/sec
 58
 73
 Temperature Control Zone
 ZONE
 4
 Material Hoppper Capacity
 L
 20
 Clamping System
 Clamping Force
 T
 40
 Opening Force
 T
 8.3
 Distance Between Tie Bars
 mm
 415×250
 The Biggest Mold Contain Space
 mm
 380×280
 Min Mold Height
 mm
 150
 Opening Stroke
 mm
 200
 Max. Open Daylight
 mm
 350
 Ejector Force
 T
 1.3
 Ejector stroke
 mm
 40
 Sliding System
 Sliding Platen Size
 mm
 -
 Sliding Platen Stroke
 mm
 -
 Round Set Diameter
 mm
 -
 Hydraulic Electric System Max. Hydraulic Pressure
 Kg/cm2
 140
 Pump Output
 L
 160
 Pump Motor Power
 Kw
 5.5
 Barrel Heating Power
 Kw
 4.1
 Total Wattage
 Kw
 9.6
 Others
 Machine Weight
 T
 2.0
 Machine Dimensions(LxWxH)
 m
 2.0×1.2×2.8
