Rdf Single Shaft Shredder Pulverizer Shredder
Changshu Shi Shouyu Machinery Co., Ltd.- After-sales Service：One Year Warranty, Life-Long Maintenance!
- Type：Rdf Shredder
- Raw Material：Waste,Metal,Plastic,Paper,Wood.
- Structure：Top Feed
- Knife Classification：Piece Knife Crusher
- Knife Roll：Solid Knife Roller
Base Info
- Model NO.：Multiple models
- Automation：Automatic
- Computerized：Computerized
- Certification：CE, ISO9001:2008, SGS,BV
- External Dimensions(mm)：1860X1200X2065mm
- Transport Package：Wooden Package,Film Package,Steel Frames Package,C
- Specification：CE,ISO9001,SGS
- Trademark：SOYU
- Origin：China
- HS Code：84778000
- Production Capacity：1000sets,Year
Description
Model
SR600
SR750
SR900
SR1100
Main shaft rev(rpm)
73
73
73
73
Pushing chamber route(mm)
500
820
820
820
Rotation diameter (mm)
φ220
φ400
φ400
φ400
Number of Rotor blades (pcs)
23
33
39
49
Number of Stator blades (pcs)
4
6
6
8
Discharge height(mm)
500
600
760
760
Screen hole diameter (mm)
40
40
40
40
Motor power(kw)
18.5
37
37~45
55~75
Hydraulic power(kw)
1.5
2.2
2.2
5.5
Cutting chamber (WXL)(mm)
600x510
830x768
900x830
1130x830
Dimension(LXWXH)(mm)
1850x1300x1700
2700X1500X2000
2700x1950x2150
2700x2300x2150
Weight(kg)
Approx 1600
Approx 3300
Approx 4100
Approx 4700
RDF Single Shaft Shredder Pulverizer Shredder
