2000bph Semi-Automatic Bottle Blow Moulding Machine
Zhangjiagang Links-Machine Co., Ltd.- Type：Stretch Blow Molding Machine
- Raw Material：PET
- Making Method of Parison：Stretch Blow
- Automation：Non-Automatic
- Computerized：Computerized
- Certification：CE, ISO9001:2008, QS, UL, GMP
Base Info
- Model NO.：LK-SA4
- Model：Lk-SA4
- Control System：Computerized
- Bottler Material：Pet
- Bottle Volume：100ml to 2500ml
- Machine Capacity：2000 Bottles Per Hour
- Machine Installation Power：30kw
- Suitable for：Water Bottle, Beverage Bottle, Oil Bottle...Ect
- Voltage：Be Designed by Customer Requests
- Certificate：SGS, ISO, Ce,..
- Weight：1300kgs
- Transport Package：Wooden Export Package
- Specification：ISO, SGS, CE
- Trademark：LINKS
- Origin：Zhangjiagang City, China
- HS Code：84774010
- Production Capacity：20,Month
Description
Electrical systemVoltage standard 380v/3PH/50Hz or special order Total power (full loaded) 18KW Container Max. container volume 2.5L Neck diameter range 15-45mm Max. container diameter 110mm Max. container height 370mm Auxiliary system High air compressor >1.2m3/3.0Mpax2 (0.5L) Dimension & weight (LxWxH) Blow molding machine 1.9x0.88x1.8m Pre-heater 1.9x0.66x1.6m Net weight 1.3T
| No | Name | Brand |
| 1 | Assembly cylinder | FESTO |
| 2 | Stretching cylinder | FESTO |
| 3 | Sealing cylinder | FESTO |
| 4 | Computer controller | BOTHFIT |
| 5 | Touch screen | BOTHFIT |
| 6 | Motor | XINGXING |
| 7 | lead rail | ABBA |
| 8 | Oil-water separator | GERMAN FESTO |
| 9 | High pressure air tank | DAFENG |
| 10 | Low pressure air tank | MG |
| 11 | Blowing valve | MG |
