• Transport Package：Plywood Case
• Model NO.：65mm
• Specification：65mm
• Trademark：OULIN
• Origin：China
• HS Code：84779000
• Production Capacity：500-700 Sets Per Year

Basic Info.

Model NO. 65mm Transport Package Plywood Case Specification 65mm Trademark OULIN Origin China HS Code 84779000 Production Capacity 500-700 Sets Per Year

Product Description

Detail Information For  Bi-Metal Battenfeld 65-22V Double Parallel Screw Barrel:

Application: for PVC extrusion, pipe, profile, sheet and etc.

Customer's Requirement:  good abrasive& corrosive resistance.

Screw's quality: bimetallic quality, screw's alloy layer contains 10%-20% tungsten carbide powder.

Barrel's quality: bimetallic quality, make slots are barrel's extruder zone, then these slots will be welded with alloy layer, alloy layer contains 10%-20% tungsten carbide powder.


Detail Information For All Brand Twin Parallel Screw and Barrel:

Application:
For the production of pipes, profiles, sheets, such as SPC floor, PVC wall board, PVC wood plastic, PE wood plastic, high molecular sheet, baking-free brick plate, high calcium plate, high calcium pipes, high calcium profiles, soft PVC sheet, PVC foam board, PP, PE, ABS, PVC, granulation and etc.

Specification:
Screw diameter: Φ45mm-Φ200mm, L/D ratio from 16-45.
we can produce twin parallel screw and barrel for all brand extrusion, experienced engineer can be sent to your factory for measuremnt.

Quality:
1: Nitriding quality------ base material: 38CrMoAlA(JIS SACM645)
2: Bimetallic quality-----Good abrasive& corrosive resistance.

Heat treatment:
Advance hardening and tempering
Nitriding treatment

Technical Parameters:
Nitriding depth: 0.50mm-0.80mm
Nitriding hardness: HRC56-58
Surface roughness: Ra 0.4
Screw straightness: 0.015mm
Alloy layer depth: 2mm-3mm
Alloy layer hardness: HRC56-64

OULIN SCREW:  YOUR LOYAL PARTNER FOR SCREW AND BARREL
