2000mm PVC Film Blowing Machine

Xiongqiu Plastic Machinery Co., Ltd.

Type：PVC Film Blowing Machine
Raw Material：PVC
Maximum Folding Width of Film：1900mm
Screw Diameter：75mm
Automation：Non-Automatic
Computerized：Non-Computerized

Base Info

Model NO.：FMC-2000
Machine Weight：4T
Certification：CE, ISO9001:2008
Machine Size：L*W*H: 4.5m * 2.05m * 4.5m
Voltage：380V 50Hz 3phase
Transport Package：Plastic Warp Film for Container Shipment
Specification：single layer
Trademark：Xiongqiu Plastic Machinery Co., Ltd.
Origin：Foshan, Guangdong Province
HS Code：8477300000

Description

PVCthickness0.02--0.10mfilm width400mm500mm600mm700mm1000mm1450mmscrew diameter Φ35mm Φ40mm Φ45mm Φ50mm Φ55mm Φ65mmL/D ratio28:1die diameter Φ40mm Φ50mm Φ60mm Φ70mm Φ80mm Φ120mmmain power11kw15kw15kw18.5kw22kw30kwmax output30kg/h40kg/h50kg/h60kg/h75kg/h95kg/hrewinder wayTorque motor winder

optional equipment

rotary die head / auto up and down

PICTURES FOR REFERENCE:
