• Model NO.：KAIDEMAC-FD
• Condition：New
• Pipe Thickness：0.15-1.1mm
• Producing Scope：16,20mm
• Machine Capacity：Max.300m,Min
• Dripper Type：1.0L,Min-8L,Min
• Machine Control：PLC Intergrated Control
• Low Voltage Electric Component：Schneider
• Frequency Inverter：ABB
• Pipe Length/Coil：2000-3000m
• Transport Package：Soft Film Packaged
• Specification：30m*3m*2.5m
• Trademark：KAIDEMAC
• Origin：China
• HS Code：8477800000
• Production Capacity：150sets,Year

Line ModelExtruderLine speedDripper recognition speedThicknessPunching speedNorminal PowerL*W*HKDPD-3SJ60250m/min2000pcs0.15-0.6mm≤950pcs118KW31m*2.5m*2.8mKDPD-2SJ60180m/min1100pcs0.15-0.6mm≤750pcs93KW31m*2.5m*2.8mKDPD-1SJ6080m/min1100pcs0.6-1.2mm≤750pcs98KW42m*2.5m*2.8m

Flat drip irrigation tape extrusion line configuration:1Automatic water dropper identifying device2Water dropper conveying device 3High efficient extruder4Die head mould5Die head screen changer6Vacuum tank7Cooling flume8vane type dehumidification device9 high speed belt puller10High speed imaging punching machine  11Auto working position coiling machine12Siemens PLC control system13Remote control system14Auxiliary machinery

Main features of the EVOH barrier pexb pipe making machine:


Control System
Advanced Siemens PCC control system was applied into this Flat drip irrigation tape line.KAIDE is the only manufacturer in China, who had successfully adopt such control system.
Intelligent functions of this system, such as whole line sync control without any deviation. One touch speed increasing or decreasing control,high precision temperature control etc,can ensure the reliable and convenient operation of the line.

Gravimeter System
High precise control system of pipe weight per meter is applied in this flat drip irrigation tape line. Such device will feed material precisely according to the weight per meter and line speed changing; to get a precise gram weight control of produced pipe. Which can shorten the start-up time and save raw materials.

Dripper sorting system
Most advanced detecting technologies are applied,such as nanoscale laser identifying device and dripper anti-direction rejecting device, ensuring drippers in production are 100% qualified.
Dripper Sorting Speed:1100pcs/min

Haul-off machine & Punching Machine
The two-stages haul-off machine of this drip irrigation pipe machine adopted servo control, and the haul-off speed can be synchronously adjusted according to the production requirement, with stable and reliable pulling, low noise.

Punching machine
This drip irrigation pipe machine is equipped with online blind-hole detecting system, once the system detects the not-punched pipe, it will cut off the pipe automatically, meanwhile change over the coiling work position, and report the waste pipe conditions on time.

Automatic Winding Machine
Automatic winding machine is driven by servo motor and controlled by SIEMENS PLC system.
Application of servo traversing and tension control system in this flat drip irrigation tape line, can ensure the high sync condition of winding speed and line speed, making winded coils even and neat.
During production, the winder can cut pipes and change reels automatically according to the setting length.

(1) HIGH SPEED: We are the highest speed production line in China, the stable production speed 150m/min, the maximum speed:180m/min.
(2) EASY TO OPERATE: Use the most advanced Simens PLC control system,which can achieve the synchronous control of the the whole line; Fully automatically pipe coiling machine, automatic to change the coil.
(3)STABLE PRODUCTION:Adopt the world famous brand, such as ABB inverter, Schneilder Electric apparatus, Simens servo motor and PLC.We have more than 20 years experience, each parts of the line are manufacture by ourselves,to be sure of the precision and good quality control.
(4)HIGH PRECISION :Punching unit adopts visual imaging PLC monitoring system, to make sure the high speed punching precision.
(5) SAVE COST :High speed improve the production efficiency; automatically function save the human being cost; Thinner Pipe Thickness:0.15mm, can save raw materials cost.
(6) GOOD APPERANCE:  With Brushed Stainless Steel Vacuum tank & cooling tank, not rustiness, good looks.
