Car Oil Bottle High Quality Extrusion Blow Molding Machine

Zhangjiagang Dawson Machine Co., Ltd.
  • Type：Extrusion Blow Molding Machine
  • Raw Material：HDPE
  • Making Method of Parison：Extrusion-Blow Molding
  • Automation：Automatic
  • Computerized：Computerized
  • Certification：CE

Base Info

  • Model NO.：ABLB80-25L
  • Application：Bottles, Jars, Jerry Cans, Gallons, Containers
  • Station：Single Station or Double Station
  • Die Head：Single Head or Double Head
  • Max. Product Volume：25L
  • Auto-Deflashing：with Auto-Deflashing
  • Clamping System：Toggle Type Clamping System
  • Mould：One Cavity or Two Cavity
  • Suitable Material：HDPE,PP,PVC,PS,PETG,LDPE
  • Sutiable：20L 25L Bottle
  • Made in：China
  • Clamping Force：270 Kn
  • Distance Between Platens：450~950mm
  • Mould Template：680× 660
  • Mould Material：S50c,Aluminium with Beryllium Copper
  • Average Power Consumption：33 Kw
  • Transport Package：Film Packing
  • Specification：ABLB80-25L
  • Trademark：DAWSON
  • Origin：Jiangsu Zhangjiagang
  • HS Code：8477301000
  • Production Capacity：50~60 PCS,H

Description

PE.PP,PVC,PS,PETG,so onMax volume25LOutput capacity50~60 PCS/HSize4.4×3.4×3.6(M)Weight11.3T SummarizeHigh efficient low power consumption plasticizion system,transducer control,self-protect function when started at low temperature ReducerHard finishing Heating power10KW/H Cooling FanSeparate cooling system for heaters         Automatic cooling     Cooling systemSummarizeSeparate cooling system of mould, barrel and oil system Cooling mediumWater Water flow100L/min Water pressure0.4-0.6MPa #blow molding machine #Extrusion Blow Molding #Injection blow molding machine  #PET blow molding machine  # injection molding machine  # blowing mould # plastic bottle making machine #plastic bottle mould #bottle machine  #plastic machinery #blow molding mould #moulding machine  # moulding mould #China blow molding machine  #blow molding machine made in China
