• Model NO.：ABA-1400
• Motor：22kw
• Output：100kgs,H
• Automatic：No
• Blow Moulding Type：Extrusion Blow Moulding
• Blower：5.5kw
• Power(W)：25kwx2
• Transport Package：Plastic Film, , Wooden Boxes, , or as Required
• Trademark：songshan
• Origin：Zhejiang, China (Mainland)

Model

ABA-900

ABA-1200

ABA-1400

main material

HDPE

film width

800mm

1000mm

1200mm

output

60kgs/H

75kgs/H

100kgs/H

screw diameter

45mm×2pcs

50mm×2pcs

55mm×2pcs

gearbox

146

146

173

motor capacity

15KW

18.5KW

22KW

die size

60mm

80mm

100mm

air blower

2.2KW

3KW

5.5KW

roller width

900mm

1200mm

1400mm

taking up speed

0-60m/min

winding type

fraction type single winder

winding diameter

650mm

Dimension

4×3×4.5M

4×3.5×6M

4.5×4×7M

Low pressure polyethylene (HDPE) and linear low density polyethylene (LLDPE) are new varieties of polyethylene in the international market. It has advantages of impact strength, penetration-resistance, environmental stress crack resistance, and low temperature resistance, especially it can be used to make micro-thin films (the film strength of 0.015 mm film is as much as that of 0.03mm high-pressure polyethylene film).

Reworked materials or other affordable materials like 50% calcium carbonate can be used without affecting the strength, weldability, printing properties of the products; and the cooling becomes faster and the yield is higher because of the calcium carbonate or low pressure polyethylene in the interlayer.
