• Model NO.：ABLD150
• Export Port：Shanghai
• Condition：New
• Company Attribute：Manufacturer
• Voltage：Customer Specified
• After-Sales Service Provided：Engineers Available to Service Machinery Overseas
• Application：Drum, Table Board, Roadblocks, Medical Bed Board
• Max. Product Volume：1500L
• Blow Molding Machine Weight：72
• Machine Dimension：11.5*7.5*8
• PLC Control：Mitsubishi
• Contactor：Schneider
• Air Valves：Airtac
• Hydraulic Valve：Taiwan Hitech
• Clamping Force：1800 Kn
• Length of Mold：1730-2200mm
• Transport Package：Film Packaging
• Specification：ABLD150
• Trademark：DAWSON
• Origin：Jiangsu Zhangjiagang
• HS Code：8477301000
• Production Capacity：as Per Samples

Basic parametersSuitable materialPEMax volume1000~5000 LOutput capacity20~25 pcs/hSize8.6×3.8×5.8 (M)Weight38 TsystemSpecificationParametersNotePlasticizion systemSummarizeHigh efficient low power consumption plasticizion system,transducer control,self-protect function when started at low temperature ReducerHard finishing,High intension,Low noise reducer Screw∮120mm,L/D ratio 28, 38CrMoALACooling system availablePlasticization320~400 Kg/HHDPEHeating Zone5~6 Aluminum HeaterAutomatic heatingHeating power36KW/H Extrusion Motor Motor 132kw (380V,50HZ) Cooling Fan5~6zone        Automatic coolingExtrusion systemSummarizeHigh-grade alloy steel, center feeding Die head number1 Center distance of die heads/ Max die mouth∮600mm Heating zone6 Stainless steel heating cycle Clamping systemSummarize
 High intension, rigidity, center mold locking, stable mould opening and clamping system  Clamping force850~900KN Template distance850~1850mm Max mould size1200X1800mm Mould materialHigh grade 50# steel Electric systemSummarizePLC+ touch screen(man-machine interface)standard extrusion blow molding machine controlling system(AUTO monitoring, fault-alarm, auto counting ,auxiliary function available)
Japanese Mitsubishi PLC
systemOperate interfaceTouch screen, automatic self-diagnose alarm system Temperature controlAutomatic temperature control module Movement controlJapanese Mitsubishi, Chinese/English
Version Electric protectionAmpere overload, electric short circuit self-protection function Hydraulic systemSummarizeMultiple function hydraulic integrated block Proportional control, high efficient Oil pump motorThree phase asynchronous motor (380V/220V,50/60HZ) 22kw Oil pumpImported double pump ValvesImported oil pump valves and connections Oil pipesDouble layer overpressure resistant System pressure60Kg/cm² Cooling systemSeparate water cooling cycle, oil cooler cooling system Pneumatic systemSummarizeTaiwan AIRTAC pneumatic system Air pressure1Mpa Air displacement1.8M3/min Electromagnetic valveAIRTAC Cooling systemSummarizeSeparate cooling system of mould, barrel and oil system Cooling mediumWater Water flow18t/h Water pressure0.3-0.6MPa
