One-Layer Plastic Sheet Extruder Cw-800b
ZHEJIANG CHINAWORLD MACHINERY CO., LTD.- Warranty：One Year
- Type：Sheet Extruder
- Plastic Processed：PP,PS,PE
- Product Type：Granulating Extruder
- Feeding Mode：One Feed
- Assembly Structure：Integral Type Extruder
Base Info
- Model NO.：CW-800B
- Screw：Single-Screw
- Engagement System：Full Intermeshing
- Screw Channel Structure：Deep Screw
- Exhaust：Exhaust
- Automation：Automatic
- Computerized：Computerized
- PP/PS/PE Machine：Plastic Sheet Extruder Machine
- Plastic Machine：Plastic Sheet Extruder
- Automatic Machine：Plastic Sheet Extruding Machine
- Transport Package：Wooden Tray
- Specification：CE
- Trademark：CHINAWORLD
- Origin：Ruian City, Zhejiang Province
- HS Code：8477209000
- Production Capacity：5sets,Month
Description
Overview
MODEL CW-800B CW-1000B CW-1200B WIDTH OF DIE HEAD 800mm 1000mm 1200mm MATERIAL PP.PS.PE PP.PS.PE PP.PS.PE WIDTH OF SHEET 750mm 900mm 1000mm THREE ROLLER SIZE 350*800mm*3 350*1000mm*3 350*1200mm*3 THICKNESS OF SHEET PP.PE:0.3-2.5mm
PS:0.15-2mm PP.PE:0.3-2.5mm
PS:0.15-2mm PP.PE:0.3-2.5mm
PS:0.15-2mm SCREW SIZE 110 1:32 110 1:32 120 1:30 TOTAL POWER 90kw 100kw 120kw WORKING POWER 55kw 60kw 72kw SPEED 15-20m/min 15-30m/min 15-50/min CAPACITY 180kg/h 220kg/h 300kg/h DIMENSION 12*1.6*2.2m 12*1.8*2.5m 11.5*1.9*2.5m WEIGHT 5800kg 6200kg 6800kg
Product Description
We adopt advanced international technology and make considerable innovations on design, manufacturing and accessories for LZ series plastics sheet extruder. The machine is mainly used to produce plastic sheet of PP, PS and PE. Then the sheet can be taken to produce such as disposable cups, jelly cups, plastic packing containers, file and so on.
Product Parameters
PS:0.15-2mm
PS:0.15-2mm
PS:0.15-2mm
