- Transport Package：Wood Cases
- Specification：Stainless Steel
- Trademark：Sky Machine
- Origin：Jiangsu
- HS Code：84773010
- Production Capacity：20 Sets,Month
| Basic Parameter | SKY-50S | SKY-60S | SKY-60D | SKY-70D | SKY-70S |
| Max.Product Volume | 2L | 5L | 2L | 5L | 16L |
| Dry Cycle | 2000 PCS/H | 1000 PCS/H | 900 PCS/H*2 | 700 PCS/H*2 | 600 PCS/H |
| Machine Barrel Screw | Φ50mm L/D=24 | Φ60mm L/D=24 | Φ60mm L/D=24 | Φ70mm L/D=24 | Φ70mm L/D=24 |
| Plasticizing | 35 KG/H | 65 KG/H | 70 KG/H | 85 KG/H | 100 KG/H |
| Heating Zone | 3 Zone | 3 Zone | 3 Zone | 4 Zone | 4 Zone |
| Mold Move Stroke | 138~368mm | 148~508mm | 138~368mm | 148~508mm | 240~620mm |
| Mold Platen Dimension | 300×340mm | 320×400mm | 300×320mm | 320×400mm | 500×550mm |
| Mold Thickness | 140-180mm | 150-250mm | 140-180mm | 150-250mm | 245-300mm |
| Total Power | 29.8 KW | 40 KW | 36 KW | 49 KW | 52 KW |
| Power Consumption | 12.2 KW/H | 13 KW/H | 14.8 KW | 17 KW/H | 30 KW/H |
| Machine Size(L*W*H)(M) | 2.5×1.6×2.3 | 2.4×1.8×2.5 | 3.1×1.9×2.8 | 2.9×2.1×2.7 | 3.5×2.1×3.1 |
| Machine Weight | 3T | 5.8T | 4.2T | 7.8T | 7.8T |
| Basic Parameter | SKY-80N | SKY-90N | SKY-100N | SKY-120N | SKY-82PC |
| Max.Product Volume | 30L | 60L | 120L | 250L | 30L |
| Dry Cycle | 650 PCS/H | 500 PCS/H | 360 PCS/H | 300 PCS/H | 650 PCS/H |
| Machine Barrel Screw | Φ80mm L/D=25 | Φ90mm L/D=25 | Φ100mm L/D=25 | Φ120mm L/D=33 | Φ82mm L/D=25 |
| Plasticizing | 100 KG/H | 120 KG/H | 140 KG/H | 300KG/H | 100KG/H |
| Heating Zone | 6 Zone | 4 Zone | 4 Zone | 6 Zone | 6 Zone |
| Mold Move Stroke | 400~830mm | 500~1050mm | 550~1400mm | 750~1750mm | 400~830mm |
| Mold Platen Dimension | 740×750mm | 1000×1200mm | 1000×1250mm | 1300×1500mm | 740×750 |
| Mold Thickness | 600×700mm | 900×1400mm | 900×1400mm | 1150×1500mm | 600×700mm |
| Total Power | 74 KW | 78 KW | 93 KW | 236 KW | 74 KW |
| Power Consumption | 38 KW/H | 46 KW/H | 48 KW/H | 128 KW/H | 38 KW/H |
| Machine Size(L*W*H)(M) | 4.2×2.3×3.5 | 4.75×2.5×3.9 | 5.4×2.6×4.2 | 7.8×3.5×5.8 | 4.2×2.3×3.5 |
| Machine Weight | 11.5T | 12.8T | 17T | 35T | 11.5T |
Certification:
Company Information
Exhibition:
Service:
1.Installation, debug
After equipment reached the workshop of customer, place the equipment according to plane layout we offered.We will arrange seasoned technician for equipment installation, debug and test production at the same time make the equipment reach the rated producing capacity of the line.Time for installation and debug is 15-25 days.
2.Training
Our company offer technology training to customer.The content of training is structure and maintenance of equipment, control and operation of equipment.Training is in the workshop of customer.Seasoned technician will guide and establish training outline.After training, the technician of buyer could master the operation and maintenance, could adjust the process and treat different failures.
3.Quality guarantee
We promise that our goods are all new and not used.They're made of suitable material, adopt new design.The quality, specification and function all meet the demand of contract.We promise that the products of this line could storage for one year without adding any aseptic.
4.After sales
1,After checking, we offer 12 months as quality guarantee, free offer wearing parts and offer other parts at the lowest price.In quality guarantee, the technician of buyers should operate and maintain the equipment according to seller's demand, debug some failures.If you could not solve the problems, we will guide you by phone;If the problems are still can not solve, we will arrange technician to your factory solving the problems.The cost of technician arrangement you could see the cost treatment method of technician.
2,After quality guarantee, we offer technology support and after sales service.Offer wearing parts and other spare parts at favorable price;After quality guarantee, the technician of buyers should operate and maintain the equipment according to seller's demand, debug some failures.If you could not solve the problems, we will guide you by phone;If the problems are still can not solve, we will arrange technician to your factory solving the problems.The cost of technician arrangement you could see the cost treatment method of technician.
FAQ:
1.Can your factory provide he whole plant from A to Z?
Yes, we can provide the complete plant, from bottling making plant,water purification plant,to filling packing plant.
2.Are all machinery your factory made?
Our factory make the water purification and filling packing plants.we do not make the bottle making machinery,we have good quality bottle making machinery partner,and we provide to customer same long warranty time and good after service.
3.How can i know the machinery quality before i order?
First,we will invite you visiting our factory to check the machines quality,and show the machines running for you in our factory.
4.What certificates you can provide?
Our factory provide the CE,SGS,ISO,and according to some countries,we also can provide the PVOC, COC,SONCAP...etc.
