Plastic Film Blowing Machine (Mini SJ-45)
Zhejiang Zhuxin Machinery Co., Ltd.- Type：PE Film Blowing Machine
- Raw Material：PE
- Maximum Folding Width of Film：500mm
- Screw Diameter：45mm
- Automation：Automatic
- Computerized：Computerized
Base Info
- Model NO.：Mini
- Machine Weight：1.8t
- Certification：CE, ISO9001:2008
- Machine Model：Mini Type
- Transport Package：Wooden Case or Stretch Film Package
- Specification：CE,ISO9001
- Trademark：Changyin
- Origin：Made in China
- HS Code：84773090
- Production Capacity：1000sets,Year
Description
Basic Info.
Model NO. Mini Machine Weight 1.8t Certification CE, ISO9001:2008 Machine Model Mini Type Transport Package Wooden Case or Stretch Film Package Specification CE/ISO9001 Trademark Changyin Origin Made in China HS Code 84773090 Production Capacity 1000sets/YearProduct Description
Performance and Characteristics:
The machinge body is channel steel frame traction frequency friction, with single rolling friction, lift up and down which is suitable for blowing high-low pressure polyethylene industral fiml and agricultural film
| Model | SJ- A 45 | SJ- A50 |
| Suitable Material | LDPE,HDPE,LLDPE | LDPE,HDPE,LLDPE |
| Screw Diameter | 45MM | 50MM |
| F ilm Width (mm) | 100- 5 00 | 3 00- 6 00 |
| Film Thickness (mm) (HD) | 0.00 9 -0.0 5 | 0.00 9 -0.0 5 |
| Film Thickness (mm) (LD) | 0.02-0.15 | 0.02-0.15 |
| Max Extrusion O utput(kg/h) (HD) | 40 | 45 |
| Max Extrusion O utput(kg/h) (LD) | 4550 | 50 |
| Screw L/D Length | 28:130:1 | 28:130:1 |
| M ain M otor(kw) | 7.5 | 11 |
| Take-up Motor (kw) | 0.75 | 1.1 |
| Outline Dimension (L × W × H)(m) | 5 . 0×2 . 0×4 .1 | 5 . 0×2 .2 ×4 .5 |
