PVC WPC Wood Plastic Composite Decking Window and Door Frame Profile Extruder Machine
Qingdao Tongsan Plastic Machinery Co., Ltd.- Output (Kg/H)：150 - 240 Kg,H
- Screw Design：Double-Screw
- Twin Screw Type：Counter-Rotating Conical Twin-Screw
- Screw Diameter (mm)：65 mm
- Screw Speed (Rpm)：1500
- Voltage：380V 50Hz 3phase(Customized)
Base Info
- Model NO.：SJ65,132
- After-Sales Service Provided：Video Technical Support, Free Spare Parts, Field I
- After Warranty Serv：Video Technical Support, Online Support, Spare PAR
- Video Outgoing-Inspection：Provided
- Machinery Test Report：Provided
- Products Size：10-3000mm Width
- Production Line Speed：0.2-0.5m,Min
- Max. Output：150-200kg,H
- Transport Package：Standred Sea Packing
- Specification：20m*1m*3m
- Trademark：TONGSAN
- Origin：Shandong China
- Production Capacity：2sets, Month
Description
Basic Info.
Model NO. SJ65/132 After-Sales Service Provided Video Technical Support, Free Spare Parts, Field I After Warranty Serv Video Technical Support, Online Support, Spare PAR Video Outgoing-Inspection Provided Machinery Test Report Provided Products Size 10-3000mm Width Production Line Speed 0.2-0.5m/Min Max. Output 150-200kg/H Transport Package Standred Sea Packing Specification 20m*1m*3m Trademark TONGSAN Origin Shandong China Production Capacity 2sets/ MonthProduct Description
Our Products:
Description of PVC window and door profile extrusion machine,WPC solid door frame making machine
1, plastic pvc profiles extrusion line is specializing in producing PVC plastic profiles including doors and windows profiles, decorative plates, tiny foaming profiles and decorative plates.
2, pvc profile machine uses PVC powder as material to produce various sorts of the mentioned plastic profiles as profiles for doors and windows, decorative profiles, etc.
3, By Absorbing advanced technology from abroad, our company developed the large plastic profile extrusion line, which is equipped with conical double-screw extruder, and it possesses the advantages of high degree automation, stable performance, high output and efficiency, etc.
4, If change certain screw and mould, the pvc profile machine can directly extrude foaming profiles, and the effect is much better than that of single-screw.
5, pvc profile extrusion line is optimumly designed by referring to the latest overseas technology, it bears the features of even plasticization, low cutting rate, high output, and long lifespan, etc. And it composes conical double-screw extruder, vacuum sizing platform, tractor, cutting and film coating machine and material stirring bracket,etc.
6, The pvc profile machine is run by alternating current frequency controller or direct current controllable silicon. The temperature controlling instrument is introduced from abroad. In addition, the vacuum pump and traction engine of the auxiliary machines are quality products which can be maintained easily
7, To match with different moulds, the shape-fixing platform of 4m, 6m, 8m or 11m, etc. can be chosen accordingly. The main machine with parallel double-screw is especially suitable for high-speed extrusion of various kinds of profiles.
| Model | SJSZ-51 | SJSZ-65A | SJSZ-80 | SJSZ-92 |
| Total Power(kw) | 25 | 64 | 115 | 168 |
| Max profile with (mm) | 200mm | 400mm | 900mm | 1500 |
| Profile products | electricity truck, house deractive line, small profiles | window and door profile, wall panel, ceiling panel | door panel, furniture panel | door panel, furniture panel |
