600mm Film Blowing Machine

Xiongqiu Plastic Machinery Co., Ltd.
  • Type：High and Low Pressure Film Blowing Machine
  • Raw Material：LDPE,LLDPE,HDPE
  • Maximum Folding Width of Film：500mm
  • Screw Diameter：45mm
  • Automation：Non-Automatic
  • Computerized：Non-Computerized

Base Info

  • Model NO.：FM-600
  • Machine Weight：2t
  • Certification：CE, ISO9001:2008
  • Machine Size：L*W*H: 4.5m * 2.25m * 4.5m
  • Voltage：380V 50Hz 3phase
  • Transport Package：Plastic Warp Film for Container Shipment
  • Specification：single layer
  • Trademark：Xiongqiu Plastic Machinery Co., Ltd.
  • Origin：Foshan, Guangdong Province
  • HS Code：8477300000

Description

LDPE / LLDPE / HDPEthickness0.02--0.20mmfilm width(mm)500400--1000400--1200160018002100max output45kgs/hr55kgs/hr70kgs/hr105kgs/hr150kgs/hr200kgs/hr Extruder30:1temp. controller5 zone5 zone5 zone6 zone6 zone8 zonebarrel cooling120w*2120w*2120w*2250w*3250w*3250w*3driving motor11kw15kw22kw30kw37kw45kw Die headSpiral mandrel die chrome plated surface 40Crcooling fan950w1.5kw2.2kw3kw4kw4kwTake up unit  partauto-loader, film surface treater, fast change net, air compressor, double center rewinder/auto-rewinder, flat cage roll rewinder, rotary die head, double wind air ring
pictures for reference:
600mm Film Blowing Machine
600mm Film Blowing Machine
600mm Film Blowing Machine
600mm Film Blowing Machine
