Mini Type Film Blowing Machine (SJ-A35)
Ruian Mingde Machinery Co., Ltd.- Type：PE Film Blowing Machine
- Raw Material：HDPE
- Automation：Non-Automatic
- Computerized：Computerized
- Certification：CE, ISO9001:2008
- Transport Package：Wooden Case
Base Info
- Model NO.：MD-HM35
- Trademark：Mingde
- Origin：China
- HS Code：8477900000
- Production Capacity：500sets,Year
Description
Basic Info.
Model NO. MD-HM35 Trademark Mingde Origin China HS Code 8477900000 Production Capacity 500sets/YearProduct Description
This machine is our new design. Especially for laboratory testing. Save electricity, low noisy.
| Max. film width | 80-400mm |
| Suitable material | HDPE, LDPE, LLDPE |
| Max. output | 15-20kg/hr |
| Film thickness | 0.008-0.05mm |
| Gear box | 133 |
| Screw diameter | φ 35mm from zhoushan |
| Screw material | SACM-645/38 CRMOALA |
| L/D | 28: 1 |
| Main motor power | 7.5kw |
| Main motor inverter | 7.5kw |
| Barrel material | SACM-645/38 CRMOALA |
| Barrel cooling | 250w× 1 |
| Barrel temp. control | 2pcs |
| Barrel heating | stainless steel |
| Die head | HD40mm |
| Die and adapator temp. control | 2pcs |
| Die and adapator heating | stainless steel |
| Air ring | 450mm |
| Fan | 1.1kw |
| Traction roller width | φ 138× 450mm |
| Traction motor power | 0.75kw |
| Traction inverter | 1.5kw |
| Traction speed | 5-80m/min |
| Wind type | single wind |
| Wind power | 5-8N. m |
| Winder speed | 5-80m/min |
| Down frame size | 200mm |
| Up frame size | 160mm |
| Power consume | 11kw |
| Aluminum roller width | 450mm |
| Machine size | 1700× 2000× 3000mm |
