• Model NO.：GZ16mm-63mm
• Condition：New
• Pipe Diameter：16-63mm
• Vacuum Calibration Tank：Vacuum Pump, Water Pump
• Vacuum Lenght：6000(1700+4300)mm
• Vacuum Pump：Yuhuan
• Water Pump：Yuhuan
• Vacuum Tank Type：Doble Chamber Vacuum Tank
• Tank Shape：Polygon
• Tank Material：Ss304
• Tank Wall Thickness：4mm
• Speed：Maximum 25m,Min
• Transport Package：Wood Case and Wood Base
• Specification：16mm-63mm
• Trademark：DEEDO
• Origin：Jiangsu, China
• HS Code：84778000
• Production Capacity：50 Sets Per Month

vacuum calibrator tank  1TypeOne chamber 2Length6000mm 3Pipe available range  4Vacuum pump quantity2(pcs)Yulong, Shanghai5Vacuum pump power4kw 6Direct connection centrifugal pump quantity2pcsYulong, Shanghai7Direct connection centrifugal pump power4kw 8Pipe line install methodTwo-way supply water and two-way drain water 9Water pump seal ringMechanical seal 10Front-back moving motor power0.75kw×2pcs 11Front-back moving methodLead screw driving 12Front-back moving range±400mm 13Left-right moving range±40mm 14Center height1000±50mm 15Tank materialStainless steel 16Plate thickness3mm 17Tank cover materialCast aluminium 18Cooling methodSpray 19Cooling MediumCooling water 20Spray pipe quantity4pcsX 2sets 21Nozzles quantityAbout 320pcs 22Nozzles specificationNew type 23Vacuum pump gas-water separator2pcs 24Water tank filter screen device25Flow meter3pcs 26Pipe carry methodNylon 27Outside seal plate specification16mm,∮20mm,∮25mm,∮32mm,∮40mm,∮50mm,63mm 28All fasteners inside the tank materialStainless steel 29Liquid level height control methodFloating ball, liquid level controller, 30Water pump blast hole diameter2" 31Total drain water pipe diameter2" 32In-water diameter1" 33ShapePolygon
