High Speed Double Color Film Blowing Machine

RUIAN YUNBANG MACHINE CO., LTD.
  • Warranty：One Year
  • Type：PE Film Blowing Machine
  • Raw Material：PE
  • Maximum Folding Width of Film：1200mm
  • Screw Diameter：50mm
  • Automation：Automatic

Base Info

  • Model NO.：SJ
  • Computerized：Computerized
  • Machine Weight：4T
  • Certification：CE, ISO9001:2008
  • Delivery：Quick
  • Speed：Quick
  • Clor：Red, Green, White
  • Standard：Light
  • Quality：High
  • Transport Package：as Requirement
  • Specification：CE. SGS
  • Trademark：YunBang
  • Origin：China
  • HS Code：8477309000
  • Production Capacity：20 Sets,Month

Description

SJ-40/700   SJ-45/900 SJ-50/1200Film width200-420mm 250-600mm300-1000mmFilm thickness0.006-0.04mm0.006-0.04mm0.006-0.04mm max output50kg/h  55kg/h75kg/hAccording to different width,thickness of film, die size and raw material characteristics to changeRaw materialHDPE/LDPE/LLDPEDiameter of screwΦ40×2,30/1
 Φ45×2,30/1  Φ50×2,30/1SACM 645 ,bimetallic ,five years guaranteeMain motor11kw  15kw18.5kw 100% Original three-phase variable frequency motor
Equipped with inverter controlTake up roller700mm900mm1200mmWeight2700kg  3100kg3800kgMachine size()5*2.1*4.35*2.2*4.8  6.5*3.2*5.8
Note:the above specifications,dimensions&design characteristics are subject to change without notice

 Optional Device:
1:EPC device  not necessary
2:Automatic edge recycling system
3:IBC COOLING SYSTEM
4:Germany film thickness and width control system
5:IBC COOLING SYSTEM
6:OSCILLATING TAKE UP UNIT
7:HEATING SLITING SYSTEM
8: GRAVIMETRIC DOSING UNIT
9:Automatic Double winder with slitting knife with PLC
10: Mick computer controller
11: faster change filter
12: 360 rotary diehead
