HDPE Plastic Kitchen Sauce Bottles Extrusion Blow Molding Machine

Zhangjiagang Dawson Machine Co., Ltd.
  • Type：Extrusion Blow Molding Machine
  • Raw Material：HDPE
  • Making Method of Parison：Extrusion-Blow Molding
  • Automation：Automatic
  • Computerized：Computerized
  • Certification：CE

Base Info

  • Model NO.：ABLB65
  • Station Number：Double
  • Material：HDPE ,PE,PVC,LDPE,ABS
  • Production：180-200PCS,H
  • Max Product Volume：5liters
  • Screw Diameter：65mm
  • Screw L/D Ratio：24 L,D
  • Screw Drive Power：18.5 Kw
  • Screw Heating Capacity：6 Kw
  • Heating Zone：3 Zones
  • Machine Weight：5.5ton
  • Clamping Force：68 Kn
  • Platen Opening Stroke：200-500 mm
  • Platen Size：360*390 mm
  • Max Mould Size (W*H)：390*390 mm
  • Mould Thickness：210-300 mm
  • Transport Package：Film Packing
  • Specification：ABLB65
  • Trademark：Dawson
  • Origin：Zhangjiagang, Jiangsu, China
  • HS Code：8477301000
  • Production Capacity：4320PCS,Day

Description

Overview Product Description



Company Profile



Packaging & Shipping



Our service



Machine features




Product Parameters



 show details




HDPE Plastic Kitchen Sauce Bottles Extrusion Blow Molding Machine
HDPE Plastic Kitchen Sauce Bottles Extrusion Blow Molding MachineOur Advantages




HDPE Plastic Kitchen Sauce Bottles Extrusion Blow Molding Machine
HDPE Plastic Kitchen Sauce Bottles Extrusion Blow Molding Machine
HDPE Plastic Kitchen Sauce Bottles Extrusion Blow Molding Machine
