Two Cavity Small Diameter 16/20/25/32/40 mm PVC Pipe Extrusion Line for Electrical Conduit ...
Zhangjiagang Beierman Machinery Co., Ltd.- Warranty：1year Since Arrive Destination Port
- Product Type：PVC Pipe
- Screw No.：Double-screw
- Automation：Automatic,Semi-Auto
- Computerized：Computerized
- Certification：CE
Base Info
- Model NO.：SJSZ-51,105
- Customized：Customized
- Condition：New
- After-sales Service：Provide Detail Installation and Operation Manual
- Motor：Siemens Brand
- Inverter：ABB,Delta,Ls
- Contactor：Schneider,Siemens Brand
- Temperature Controller：Omron,FUJI,Rkc Brand
- Transport Package：Film, Container
- Trademark：BEIERMAN
- Origin：China
- HS Code：84772090
- Production Capacity：20sets Per Month
Description
Product Description
PVC pipe production line, we can supply different machines for diameter from 16mm to 800mm .
For different diameter range pipe,will be equipped with corresponding different production lines.
we can supply PVC pipe production lines for diameter:
16mm,20mm,25mm,32mm,40mm,50mm,63mm,
75mm,90mm,110mm,125mm,160mm,200mm,250mm,280mm,315mm,355mm,400mm,
450mm,500mm,550mm,630mm,710mm,800mm.
16-40mm PVC 2 pipe production line with SJSZ51/105 or SJSZ55/120 or SJSZ65/132 conical twin screw extruder as main extruder,
equip with GF series auxiliary machinery, specially designed for PVC pipe(UPVC,CPVC share machines), is mainly used in the area of agricultural water supply system, architectural water supply system, pavement of cables, etc .
The line is conical twin screw extruder equipped with double single-control stainless steel vacuum spraying calibration, it avoids waste condition when one tube is adjusted and the other one is affected. The auto single-control double hauling off machine ane cutting machine are combined with the front double calibration technology to make operation more flexible.
for those small diameter pipe,such as not more than 32mm pipe, can 4 cavity;
such as not more than 110mm diameter pipe, can 2 cavity.
for those big diameter pipe, such as more than 110mm, will be single cavity.
Pipe Diameter range: 16mm, 20mm, 25mm, 32mm, 40mm, Two Pipe Outlets.
Major parts of High quality 16-40mm two cavity PVC pipe production line with SJSZ51/105 as main extruder :
the 16-40mm complete 2 cavity PVC pipe production line will include:
1,DTC-600 screw conveyor;
2,SRL-Z200/500 PVC powder hot/cold mixer unit;
3,ZJF300 spring conveyor;
4,SJSZ51/105 conical twin screw extruder;
5,mould for 16-40mm diameter, two cavity
6,vacuum forming tank,two cavity
7,haul off-cutting machine, two cavity
8, stacker(or belling machine,up to customer's choice)
Detailed Photos
Packaging & ShippingCompany Profile- BEIERMAN MACHINERY was established by three skilled technician/engineer/sales for plastic extruding line, plastic recycling lines producing, sale and services.
- We have 3000 square meters working house for machines making, there are 40 workers for machines producing and a 5 engineers service team for the machines running test, installation, workers training and machines repairmen.
- we have already get CE certificate for our machines and factory, which ensured the high quality level of all machines we are producing
- we will attend several home and abroad plastic machines industry fairs to show the customers our quality, machines and services.
- there will be 1-2 new produced machines will be showed to the customers every year.
- we already established cooperation with the customers from Middle East, Southeast Asia and south America countries.After Sales Service
