Plastic Machinery

HDPE Pipe Production Line/PVC Pipes Production Line/HDPE Pipe Extrusion Line/PVC Pipe ...

ZHANGJIAGANG QING CHEN YU MACHINERY CO., LTD.
  • Product Type:PE Pipe
  • Screw No.:Single-screw
  • Automation:Automatic
  • Computerized:Computerized
  • Certification:CE
  • Customized:Customized

Base Info

  • Model NO.:315-630MM
  • Condition:New
  • HDPE Pipe Production Line:20-1200mm Pipe Range
  • HDPE Gas Pipe Machine:PE Water Pipe
  • 315-630mm:1200mm
  • Transport Package:Wood Pallet Covered by Film
  • Specification:C. E
  • Trademark:XJG
  • Origin:China
  • HS Code:8477800000
  • Production Capacity:Uncertain

Description

Basic Info.

Model NO. 315-630MM Condition New HDPE Pipe Production Line 20-1200mm Pipe Range HDPE Gas Pipe Machine PE Water Pipe 315-630mm 1200mm Transport Package Wood Pallet Covered by Film Specification C. E Trademark XJG Origin China HS Code 8477800000 Production Capacity Uncertain

Product Description

Machine Characteristics 1. The optimum spiral structure feeding throat highly improves the output of extruder 2. Accurate temperature control system ensures materials melting performance 3. Unique screw design achieves better plasticizing and high quality products 4. Precisely designed gearbox with a high torsion guarantees stable running 5. "H" shape frame to decrease vibrating of extruder 6. Advanced PLC operation system realizes synchronization and automation  7. Adopt automatic water temperature & level control and special independent filters on both vacuum and cooling tanks 8. Offer stable haul-off unit with 2-12 caterpillars 9. Provide saw & chip-free cutting options 10. Low energy consumption, excellent performance, and easy maintenance
HDPE Pipe Production Line/PVC Pipes Production Line/HDPE Pipe Extrusion Line/PVC Pipe Production Line/PPR Pipe Production Line
HDPE Pipe Production Line/PVC Pipes Production Line/HDPE Pipe Extrusion Line/PVC Pipe Production Line/PPR Pipe Production Line
Pipe ranger(mm)20-6350-160150-250250-315280-630
ExtruderSJ65/33SJ75/33SJ90/33SJ120/33SJ150/33
Capacity(kg/h)50-8080-150180-260300-400450-600
Total power(kw)75145195220350
Line length3538424456
Control systemPLCPLCPLCPLCPLC
