• Model NO.：PXB110B
• Bottom Blowing：Available
• Material：PP, PE, ABS...
• Total Weight：24t
• Output(Dry Cycle)：300 PC,Hr
• Die Head Option：Accumulator Head
• Transparent Line：Available
• Production Usage：Toys, Auto Parts, Drum, etc
• Multi-Layer：Available
• Multi-Color：Available
• Screw Diameter：110mm
• Transport Package：Film Packing with Wooden Bottom
• Specification：Max capacity 250L
• Trademark：Puxin
• Origin：Jiangsu
• HS Code：847730100

PE,PP,ABS... Max container capacityL250 Output(dry cycle)pc/hr300 Machine dimension(L×W×H)M6.8×3.3×5.0 Machine weightT24 Clamping Unit   Clamping forcekn1000-1200Mold platen size(W×H)mm1300×1400 Platen opening strokemm600-1600 Platen moving strokemm1000 Max mold size(W×H)mm1100×1700 Mold thicknessmm610-750 Power   Servo oil pump motor powerKW22 Servo pump displacementL/MIN150 Blow pressureMPA1 Air consumptionM3/MIN1.8 Cooling water pressurempa0.5 Water consumptionL/min60 Average energy consumptionKW70-80 Extruder unit   Screw diametermm110 Screw L/D ratioL/D25HDPE Melting capacit for HDPEkg/hr180-250 Number of heating zonezone6 Screw heating powerkw30.2 Screw fan powerKW0.6 Extruder motor powerkw75(90) Die head   Number of heating zone for single die headzone6 Heating power for single die headkw31.2 Max die-pin diametermm550 Accumulator capacityL15(20)(HDPE) Accumulator weight(HDPE)KG11(15)
Delivery Time:
- No later than 75 days after receipt of the deposit

Training:
- We provide training service for two or three operating men for free (but the cost for trainer's board and lodging is not included).

Installation:
- The supplier will send one specialist to test run the machine until it is running in normal state.

Guarantee:
- Our guarantee is valid for a period of 12 months. If the malfunction caused of the machine's self quality, we will troubleshoot it for free.

Auxiliary Equipments:
- Auxiliary equipments for production line are available and optional, please kindly ask for quotation.
