• Model NO.：EK8806
• Computerized：Computerized
• Certification：CE, ISO9001:2008
• Productivity：8000-10000 Pairs, 24hours
• Transport Package：Container
• Specification：ISO, CE
• Trademark：KCLKA
• Origin：Fujian, Jinjiang
• HS Code：84773090
• Production Capacity：20 Sets, Month

Basic Info.

Model NO. EK8806 Computerized Computerized Certification CE, ISO9001:2008 Productivity 8000-10000 Pairs/ 24hours Transport Package Container Specification ISO, CE Trademark KCLKA Origin Fujian, Jinjiang HS Code 84773090 Production Capacity 20 Sets/ Month

Product Description

Specifications
Upper Molding machine is used to make three-color PVC or TPR upper, sole and stepping-pad of electronic bile and motorcycle, etc

Upper Molding Machine  EK-8806

Feature:
1. This machine can be used to make three-color PVC or TPR upper, sole and stepping-pad of electronic bile and motorcycle, etc.
2. Humanized man-machine interface, PLC controlling, touch-screen display.
3. Double-ratio hydraulic system;
4. Accurate digital measurement;
5. Rational layout, easy to operate and it can be run without professionals;
6. Energy-saving ,less laborer, high production;
7. Master and slave can be exchanged mutually to use, it has stronger adaptability, single color, double color and three color can be chosen freely.
8. This machine has large injection force, clamping force and can make large size products is high when producing large size shoes.

Specifications:

Item	Unit	Specification
Model		EK-8806
Raw material		PVC
station number	Pcs	6,8
Screw diameter	mm	60, 45x2
Screw speed	r/pm	0-155
Max Injection capacity	cm3	565, 240x2
Injection hydraulic	Mpa	80
Clamping force	Kn	100T
Power of motor	kw	15,11
Heating power	kw	16
Limit of temperature	point	4
Model size L*W*H (max)	mm	400*400*110
Machine size	mm	6300*2850*1920
Machine weight	Kg	About 10000
Daily Production	Pairs/24 hours	8000-10000
