• Machine Weight：4T
• Certification：CE
• Screw Material：Double Alloy
• Die Head：Rotary Head
• Heater Material：Cast Aluminum
• Motor：China , Siemens Is Optional
• Inverter：China ,Delta or Panasonic Is Optional
• Electric Parts：Schneider ,Panasonic
• Temperature Control：Omron
• Gear Box /Reducer：Shuguang ,Hangzhou Weili
• Winder：Sing , Double
• Air Ring：Double-Lip Air Ring
• Transport Package：Plastic Film ,Bubble Film
• Specification：600mm
• Trademark：E-SHION
• Origin：China
• HS Code：8477309000
• Production Capacity：100sets,Year

Model

SJ-45/FM600

SJ-55/FM800

SJ-60/FM1000

SJ-65/FM1200

SJ-80/FM1500

SJ-100/FM2000

Screw Diameter

45mm

55mm

60mm

65mm

80mm

100mm

Screw Ratio

L/D28:1

L/D28:1

L/D28:1

L/D28:1

L/D28:1

L/D28:1

Screw Speed

10-100r/min

10-100r/min

10-100r/min

10-100r/min

10-100r/min

10-100r/min

Power of Main Motor

7.5kw

11kw

15kw

18.5kw

30kw

55kw

Max. Extrusion output

35kg/h

50kg/h

65kg/h

76kg/h

86kg/h

160kg/h

Max. Folding Width of Film

600mm

800mm

1000mm

1200mm

1500mm

2000mm

Single-sided Thickness of Film

0.006-0.10mm

0.006-0.10mm

0.006-0.10mm

0.006-0.10mm

0.01-0.10mm

0.01-0.10mm

Total Power

18kw

22kw

28kw

32kw

52kw

80kw

Weight of Machine

2000kg

2200kg

2800kg

3300kg

4300kg

5800kg

Overall Dimensions

(L×W×H)

4200×1800

×3600mm

4400×2000

×4000mm

4600×2300

×4200mm

4800×2500

×4500mm

5200×2800

×5000mm

5800×3300

×6000mm
