Haitian Htf200X 50mm Injection Screw and Barrel for UPVC Fitting
ZHOUSHAN JINTANG OULIN MACHINERY CO., LTD.- After-sales Service：If Has Quality Defects, a New One Will Be Made.
- Warranty：180 Days
- Standard：DIN, JIS
- Technics：Cutting, Heat Treatment, Pta Welding, Casting
- Feature：Long Working Life
- Material：Alloy Steel
Base Info
- Model NO.：50mm
- Transport Package：Plywood Case
- Specification：50mm
- Trademark：OULIN
- Origin：China
- HS Code：84779000
- Production Capacity：400-600 Sets Per Year
Description
Basic Info.
Model NO. 50mm Transport Package Plywood Case Specification 50mm Trademark OULIN Origin China HS Code 84779000 Production Capacity 400-600 Sets Per YearProduct Description
Detail Information For HAITIAN HTF200X 50mm Injection Screw and Barrel for UPVC Fitting:Application: for HAITIAN injection molding machine, UPVC with little CaCo3
Customer's requirement: good corrosive resistance, screw is coated with hard chrome
Screw's quality: nitriding quality, choose 38CrMoAIA as base steel, be coated with hard chrome.
Barrel's quality: nitriding quality, choose 38CrMoAIA as base steel.
Detail Information For All Brand Injection Molding Screw and Barrel:
Brief introduction:
it can be used in vertical& horizontal type injection molding machine, has different quality for different working sotuation, we can design it according to different material or customers'requirements.
Specification:
Diameter: Ø20mm-Ø300mm
Clamping force: 100KN-35000KN
Shot weight: 30g-30000g
Quality:
there are many different quality can be chosen, from normal nitriding quality to best abrasive& corrosive resistance, welcome to contact us.
Heat treatment:
Advance hardening and tempering
Nitriding treatment
Mid/high-frequency quenching
Vacuum hardening
Technical Parameters:
Nitriding depth: 0.50mm-0.80mm
Nitriding hardness: HRC56-58
Surface roughness: Ra 0.4
Screw straightness: 0.015mm
Alloy layer depth: 3mm
Hardness for alloy layer/ fully hardened screw: HRC56-64
OULIN SCREW: YOUR LOYAL PARTNER FOR SCREW AND BARREL
