Two Layer Co Extrusion Rotary Die Head Film Blowing Machine
Ruian Hoin Machinery Co., Ltd.- Type：Multi-Layer Co-extrusion Film Blowing Machine
- Raw Material：PE
- Automation：Semi Auto
- Computerized：Computerized
- Certification：CE, ISO9001:2008
- Certificate：CE,ISO9001
Base Info
- Model NO.：F2B-RD-800, 1000, 1200, 1500, 1700, 2000, 2500, 3m
- Guarantee：One Year
- Feature 1：Rotary Die Head
- Feature 2：Double Layer Film Extruding
- Feature 3：High Output
- Optional Part：High Speed Net Changer
- Optional Parts：Digital Corona Treater
- Transport Package：Stretch Film or Wooden Case
- Specification：CE, ISO9001
- Trademark：HONGQI
- Origin：Ruian, Zhejiang, China
- HS Code：84773010
- Production Capacity：30 Set,Month
Description
| MODLE | F2B-RD-800 | F2B-RD-1000 | F2B-RD-1200 | F2B-RD-1500 |
| Suitable material | LDPE LLDPE HDPE | |||
| Layfat width of film(mm) | 800 | 1000 | 1200 | 1500 |
| Thickness of film(mm) | 0.02-0.10 | |||
| Max.extrusion output | 75kg/h | 100kg/h | 120kg/h | 140kg/h |
| Screw dia(mm) | Φ45x2 | Φ50x2 | Φ55x2 | Φ60x2 |
| Screw L/D | 30:1 | |||
| Screw rotation | 10-100r/min | |||
| Main motor(kw) | 11x2 | 15x2 | 18.5x2 | 22x2 |
| Dia of orifice(mm) | Φ200 | Φ250 | Φ300 | Φ350 |
| Rir ring structure form | Double air vent air ring | |||
| Rotary traction form | 360° 360°continuous rotation | |||
| Tota power(kw) | 40 | 45 | 55 | 70 |
| Weight (T) | 3.5 | 4 | 5 | 5.5 |
| Dimension LxWxH(M) | 4x3x4.4 | 4.2x3.2x4.6 | 4.6x3.4x5 | 5.2x3.7x6 |
| MODLE | F2B-RD-1700 | F2B-RD-2000 | F2B-RD-2500 | F2B-RD-3000 |
| Suitable material | LDPE LLDPE HDPE | |||
| Layfat width of film(mm) | 1700 | 2000 | 2500 | 3000 |
| Thickness of film(mm) | 0.03-0.10 | |||
| Max.extrusion output | 140kg/h | 175kg/h | 200kg/h | 230kg/h |
| Screw dia(mm) | Φ60x2 | Φ70x2 | Φ80x2 | Φ90x2 |
| Screw L/D | 30:1 | |||
| Screw rotation | 10-100r/min | |||
| Main motor(kw) | 22x2 | 37x2 | 45x2 | 55x2 |
| Dia of orifice(mm) | Φ420 | Φ500 | Φ600 | Φ700 |
| Rir ring structure form | Double air vent air ring | |||
| Rotary traction form | 360° 360°continuous rotation | |||
| Total power(kw) | 80 | 120 | 150 | 180 |
| Weight (T) | 6 | 8.5 | 11 | 13 |
| Dimension LxWxH(M) | 5.2x4x6.2 | 8x4.2x8 | 9x4.5x9.6 | 10x5x11 |
