2liter Double Station Single Die-Head Double Layer View Stripe Blow Molding Machine

Suzhou OTO Machinery Co., Ltd.
  • Warranty：One Year
  • Type：Extrusion Blow Molding Machine
  • Raw Material：HDPE, LDPE, PP, PVC, PETG...
  • Making Method of Parison：Extrusion-Blow Molding
  • Automation：Automatic
  • Computerized：Computerized

Base Info

  • Model NO.：TK-2D-1-P-T
  • Certification：CE, ISO9001:2008, UL
  • After-sales Service：One Year
  • Max. Volume：2 Litre
  • Station：Double
  • Die Head：Single
  • Layer：Single
  • Screw Diamter：φ60mm
  • Screw L/D Ratio：25:1
  • Output of HDPE：60kg
  • Extruder Driving Power：15kw
  • Oil Pump Motor Power：5.5kw
  • Clamping Force：45kn
  • Platen Opening Stroke：138~368mm
  • Platen Size：280*320mm
  • Dimension：3600*2260*2200mm
  • Weight：5.5ton
  • Air Pressure：0.8MPa
  • Transport Package：Wooden Case, PE Film
  • Specification：17CBM
  • Trademark：OTO
  • Origin：China
  • HS Code：847740
  • Production Capacity：170 Sets,Year

Description

Basic Info.

Model NO. TK-2D-1-P-T Certification CE, ISO9001:2008, UL After-sales Service One Year Max. Volume 2 Litre Station Double Die Head Single Layer Single Screw Diamter φ60mm Screw L/D Ratio 25:1 Output of HDPE 60kg Extruder Driving Power 15kw Oil Pump Motor Power 5.5kw Clamping Force 45kn Platen Opening Stroke 138~368mm Platen Size 280*320mm Dimension 3600*2260*2200mm Weight 5.5ton Air Pressure 0.8MPa Transport Package Wooden Case, PE Film Specification 17CBM Trademark OTO Origin China HS Code 847740 Production Capacity 170 Sets/Year

Product Description

2 Liter Double station Single Die-head Double Layer With View Striple Automatic Extrusion Blow molding machine with conveyor, leak testing, in-mold labeling machine for optional
2liter Double Station Single Die-Head Double Layer View Stripe Blow Molding Machine
