Plastic Machinery

Automatic 3D Air Duct Blow Molding Machine

Suzhou OTO Machinery Co., Ltd.
  • Warranty:One Year
  • Type:Extrusion Blow Molding Machine
  • Raw Material:Teee,TPV,PA6
  • Making Method of Parison:Extrusion-Blow Molding
  • Automation:Automatic
  • Computerized:Computerized

Base Info

  • Model NO.:TBC-70A
  • Certification:CE, ISO9001:2008, QS, UL
  • After-sales Service:One Year
  • Transport Package:Wooden Case
  • Specification:32CBM
  • Trademark:OTO
  • Origin:China
  • HS Code:847740
  • Production Capacity:300set,Year

Description

Screw Diameterφ70mmL/D30:1Output70kg/hMold Platen Dimension700*900mmMold Platen Opening Stroke550~1100mmPressure14MPaClamping Force100KNAccumulator Volume2LMax. Die Diameter40mmFrame Lifting Stroke300mmExtruder Heating power19kwDie Head Heating Power16kwExtrusion Motor Power37kwServo Oil Pump Motor Power11kwAxial Wall Thickness Motor Power11kwRadial Wall Thickness StrokeXY Direction6mmRadial Wall Thickness Motor Power4kw*2Total Rated Power82kwAverage Power Consumption31kwMachine Dimension(L*W*H)6300*3500*4400mmMachine Weight12Ton
Automatic 3D Air Duct Blow Molding Machine
