• Model NO.：ycq-5l-2
• Cavity：2
• Theory Output：1500-2000PCS,Hr
• Max. Volume：5L
• Power：51kw
• Size of The Machine：4.7X1.6X1.9 (M)
• Weight of The Machine：3000kg
• Raw Material：PET
• Making Method of Parison：Stretch Blow
• Automation：Automatic
• Computerized：Computerized
• Certification：CE
• Transport Package：Wooden Package or as Customer′s Request
• Specification：ce iso sgs
• Trademark：eceng
• Origin：Zhangjiagang Jiangsu
• HS Code：8477300000
• Production Capacity：6-8sets Per Month


Bottle type specification
 cavity2theory output (PCS/HR)1500-2000Max. volume (L)5LBottle mouth maximum overall diameter (mm)150mmBottle biggest diameter180mmBottle maximum height400mm
Power specifications
 Light tube quantity32pcsLight tube power2kwMaximum heating power64kwAll electric machine installation67kwActual consumption46.9kw
Air pressure specification
 Work pressure7-9kg/cm2Low-pressure gas consumption1600Ltr/minBlow bottle pressure25-35kg/cm2Higher -pressure gas consumption4000 Ltr/min
Frozen water specification
 Work pressure5-6 kg/cm2Temperature range10Consumption8000kcal/hrFrozen water flow88Ltr/minMachine specificationSize of the machine4.7x1.6x1.9 (m)Weight of the machine3ton
