• Model NO.：MD-HL65
• Certification：CE, ISO9001:2008
• Gear Box：200kg,Hr
• Transport Package：Film Packing
• Trademark：Mingde
• Origin：China

Basic Info.

Model NO. MD-HL65 Certification CE, ISO9001:2008 Gear Box 200kg/Hr Transport Package Film Packing Trademark Mingde Origin China

Product Description

MD-HL series high and low pressure film blowing machine
Main Technical Parameters
ModelMD-HL50MD-HL55MD-HL60MD-HL65
Suitable MaterialHDPE/LDPE/LLDPE
Max Film Width(mm)60080010001200
Film Thickness(mm)HD: 0.008-0.08
LD: 0.02-0.15
Max Extrusion Output HD40kg/hr50kg/hr60kg/hr80kg/hr
LD50kg/hr60kg/hr70kg/hr100kg/hr
Extrusion unit
Gear Box146173173200
Screw Diameter(mm)φ 50φ 55φ 60φ 65
Screw L/D Ratio28: 128: 128: 128: 1
Screw's Material38 CRMOALA
Barrel's Material38 CRMOALA
Barrel's Cooling Fan250W× 2370W× 2370× 2370× 2
Thermo Control (zone)3334
Driving Motor (kw)1118.52230
Extrusion Die
Die Size (mm)HD: φ 60HD: φ 80HD: φ 100HD: φ 120
LD: φ 150LD: φ 180LD: φ 220LD: φ 250
Die Rotary Device360° Continue Rotary 360°
Screen ChangerStandard manual
Thermo Control (zone)2222
Air Ring (mm)φ 620φ 760φ 760φ 760
Cooling Blower (kw)1.52.22.23
Center Steady Stick1 PCS
Take-UP Unit
Roller Width (mm)φ 138× 650φ 138× 850φ 138× 1100φ 138× 1300
Embossing Roller Width550mm750mm1000mm1200mm
Take-UP Motor (kw)0.751.11.11.5
Take-UP Speed(M/min)10-6010-6010-6010-60
Height adjustable type700mm
Winding Unit
Type OF WinderSurface Friction Winder
Roller Width (mm)70090011001300
Winding Motor (N. M)6101016
Winding Speed(M/min)10-6010-6010-6010-60
Voltage380V, 50HZ, 3PHASE
Cover Dimensions (m)4.5× 2.0× 4.34.5× 2.2× 4.55× 2.5× 4.85.5× 2.8× 5.2







OPTIONAL EQUIPMENT




1)AUTO LOADER


2)DOUBLE WINDER


3)CORONA



4)AIR SHAFT



5)MANUAL MECHANICS SCREEN CHANGER

6)FULL AUTOMATIC WINDER

7)AUTOMATICALLY SUPPLY AIR
