• Model NO.：PPD-3PLY800
• Max.Diameter of Rewinding：180mm
• Rewind Paper Core Dia：12.7,16,25mm or (or as Request)
• Coreless Rewind Inner Dia：8mm-12mm by Buyer Requiremnet
• Max. Speed of Slitting  ：150m,Min
• Transport Package：Packing in Standard Export Wooden Case
• Specification：Machine Model
• Trademark：PPD
• Origin：China(Mainland)
• HS Code：84411000
• Production Capacity：10units,Month

Basic Info.

Model NO. PPD-3PLY800 Max.Diameter of Rewinding 180mm Rewind Paper Core Dia 12.7/16/25mm or (or as Request) Coreless Rewind Inner Dia 8mm-12mm by Buyer Requiremnet Max. Speed of Slitting   150m/Min Transport Package Packing in Standard Export Wooden Case Specification Machine Model Trademark PPD Origin China(Mainland) HS Code 84411000 Production Capacity 10units/Month

Product Description

Good sale 3ply carbonless paper cutting rewinding machine adopts Simens PLC Touch screen for premium quality standard.

This machine can make the 1ply,2ply,3ply of different paper roll products,includes carbonless paper roll,NCR roll,POS roll,ATM roll etc.It is multi-funcitonal machine for different purpose of paper converting.

 Machine adopts Siemens PLC  HMI for programmer to control system,include LCD color  touch screen, all the automation working condition are displayed on the  LCD for very simple operation.

 The main motor adoptsSiemens   inverter motor, and frequency inverter control.

 Machine designed with automatic chain loading system for jumbo roll with individual motor control

 All the rollers have been precise dynamic static balance treated

 Machine design with end mark line marking  system, printing the color line at the end of paper rolls to alarm to replace paper roll.

 Machine designed with cycle knife  cutting system and with automatic wastage edge trimming system.

 It adopts auto tension for adjust the tension to contol the roll tight or loosen as buyer option

 It adopts wastage collection system with fan to blow the waste to side of the machine to collect.

 With precise automatic meter counter wheel,   when it reach seting length, the machine automatic stop.

 Machine with working light on the top of rewinding area to more bright of rewinding area.

 It equipped with emergency   switch.bearing house to protect for CE certificate standard.



Model Number	PPD-3PLY800
Max. Parent Roll Web Width	800mm
Max  Parent Roll Web Diameter	1000mm
Max. Rewinding Roll Diameter	180mm
Minimum Slit  Roll Width	25mm
Max  Machine Speed	150meter/minute
Unwinding Roll Shaft	76mm/3" Air Shaft
Rewinding Roll Shaft	12.7/16/25mm or (or as   request)
Gross Weight	1500kg
Overall Dimensions	2500x1700x1500mm LWH

FAQ:
1 Q: Which machine do you require?
A: We have many models of machine, please contact our sales office who will assist you to select the best machine to suit your requirements.
2 Q: Can you make the machines as buyers' requests for us?
A:Yes. We have a professional RD team with rich experience to design and manufacturing.
3 Q: What is your terms of payment ?
A: T/T or L/C 30% deposit ,the balance after inspection and before shipment.
4 Q: How long is the warranty?
A: Machine with one year warranty, if any parts broken,we will send new spare parts to buyer via DHL within 24 hours,life-long maintenance
5 Q: How long is your delivery time?
A: 3 weeks for Standard model machine,30 working days for customized model.
6 Q:How do you pack the machine?
A: Free fumigation plywood cases
7Q:How do you deliver the machine?
A:By sea,by air,by road
8 Q: Will you support oversea service?
A: Yes, our engineer can go to buyer's factory to install the machine and train the operator for buyer.
We can also provide 2 days free training in our factory,with food and accommodation.
