High Speed Hot Sale Bottle Making Machine for Milk Bottles

Zhangjiagang Borun Machinery Co., Ltd.
  • Type：Extrusion Blow Molding Machine
  • Raw Material：PE
  • Making Method of Parison：Extrusion-Blow Molding
  • Automation：Automatic
  • Computerized：Computerized
  • Certification：CE, ISO9001:2008

Base Info

  • Model NO.：BM
  • Suitable Material：PE,PP, HDPE, LDPE
  • Oil Pump：Hitech
  • Hydraulic Valve：Northman
  • Contactor：Schneider
  • Proximity Switch：Riko
  • Touch Screen：Hitech
  • Microcomputer Control System：Mitsubishi
  • PLC：Mitsubishi
  • Air Valve：Airtac
  • Machine Name：High Speed Hot Sale Bottle Making Machine for Milk
  • Transport Package：Plastic
  • Specification：500ml-200L
  • Trademark：BORUN
  • Origin：China
  • HS Code：84774010
  • Production Capacity：500PCS,Year

Description

ModelUnitBM-50SBM-60SBM-80SBM-60DBM-70DMax. Product volumeL2.562526Dry clclePcs/h15001200600700x2600x2Screw diameterMm5060806070Screw L/D ratioL/D24-3024-3025-3024-3024-30Screw drive powerKW11-1515-18.537-4515-18.518.5-30Screw heating capacityKW7.8-8.510.8-1216-2010.8-1212-14.5Output of HDPEKg/h30-3560-68120-14060-6870-85Oil pump drive powerKW5.55.5225.55.5-7.5Clamping forceKN35682003568Platen distancemm138-368178-538400-900138-368178-538CapacityL  4.8  Max. Die diameterMm9015030090150Central distance of bi-dieMm110-130130-200 130-150150-200Max. Die diameter
(Bi-die)mm55100 80100Central distance of three-dieMm80-110100-120 80-110110-140Max. Die diameter(three-die)Mm4060 4070Central distance of four-dieMm60-8560-85 60-8570-100Max. Die diameter
(four-die)Mm2530 2545Die heat capacityKW  16  The average consumptionKW/H12.516.53216.518.5Blowing pressureMPa0.60.60.80.60.6Air volumeM³/min0.40.50.80.40.4Cooling water pressureMPa0.2-0.30.2-0.30.30.30.3Water consumptionL/MIN3050806070DimensionL*W*H2.8*1.8*2.3m3.0*1.9*2.5m4.3*2.2*3.6m3.0*2.15*2.6m3.5*2.1*2.6mWeightTon34.512.56.57.8COMPONENTSUPPLIERSOIL PUMP                TAIWAN HITECH          HYDRAULIC VALVE       TAIWAN NORTHMAN          COMPONENTSUPPLIERSMICROCOMPUTER CONTROL SYSTEMJAPAN MITSUBISHI PLC    TOUCH SCREEN   TAIWAN HITECH TOUCH SCREEN
(COLORFUL, BILINGUAL)     TEMPERATURE MODULE  TAIWAN 7118R       PROXIMITY SWITCH      TAIWAN  RIKO                 CONTACTOR            FRANCE SCHNEIDER         MOTOR                   SIEMENS BEIDE THREE PHASE MOTORPOWER RESOURCE       TAIWAN MEAN WELL           TANSDUCER             TAIWAN DELTA                 COMPONENTSUPPLIERSAIR VALVE               TAIWAN  AIRTAC               High Speed Hot Sale Bottle Making Machine for Milk Bottles
