- Model NO.：GZ315-630mm
- Condition：New
- Pipe Diameter：315mm-630mm
- Vacuum Calibration Tank：Vacuum Pump, Water Pump
- Vacuum Lenght：6000(1700+4300)mm
- Vacuum Pump：Yuhuan
- Water Pump：Yuhuan
- Vacuum Tank Type：Double Chamber Vacuum Tank
- Tank Shape：Polygon
- Tank Material：Ss304
- Tank Wall Thickness：4mm
- Inlet Water Diameter：2inches
- Transport Package：Wood Case and Wood Base
- Specification：630mm-1600mm
- Trademark：DEEDO
- Origin：Jiangsu, China
- HS Code：84778000
- Production Capacity：50 Sets Per Month
| Double-cavity calibrator | | |
| 1 | Vacuum tank | Double -cavity spray | |
| 2 | Length | 6000(1700+4300)mm | |
| 3 | Pipe diameter | Φ315mm-630 mm
12''-24'' | |
| 4 | Vacuum pumps | 2pcs | Yuhuan, Shanghai |
| 5 | Vacuum pump power | 5.5+7.5KW | |
| 6 | Water pumps | 2pcs | Yuhuan, Shanghai |
| 7 | water pump power | 7.5KW | |
| 8 | Water pump sealing ring | Mechanical sealing | |
| 9 | Front-back moving motor power | 1.1KW | |
| 10 | Front-back moving range | ±500mm | |
| 11 | Moving channel centre height | 980mm | |
| 12 | Channel specification | No 8 light channel | |
| 13 | Front-back moving method | gear ,rack | |
| 14 | Left-right moving range | ±40mm | |
| 15 | Central height | 1200±50mm | |
| 16 | Tank material | Stainless steel | |
| 17 | Thickness of plate | 5mm | |
| 18 | Tank cover material | Cast-aluminum | |
| 19 | cooling method | Spray | |
| 20 | cooling medium | Cooling water | |
| 21 | Spray pipes | 8pcs | |
| 22 | Nozzles | About 320pcs | |
| 23 | Nozzle specification | 1"× Φ4 | |
| 24 | Water recycling filters | 2pcs | |
| 25 | Water recycling filter specification | 2 | |
| 26 | pipe carrying method | rolling wheel | |
| 27 | Outlet sealing plate | Due to customers | |
| 28 | all components and structure of the tank | Stainless steel | |
| 29 | Liquid level controlling method | Floating ball +electromagnetic valve +level controller | |
| 30 | Water inlet | 11/2" | |
| 31 | Water outlet | 1" | |
| 32 | Dimension of the tank | polygon | |
