PVC Pipe Bending Machine for PVC Bending (160mm)
Zhangjiagang Yusheng Machinery Co., Ltd.- Product Type:PVC Pipe
- Screw No.:Multi-screw
- Automation:Automatic
- Computerized:Computerized
- Certification:CE
- Customized:Customized
Base Info
- Model NO.:160mm
- Condition:New
- Size:75-160mm
- PLC:Siemens
- Touch Screen:Siemens
- Temperature Controller:Omon
- Control:PLC Automatic
- Transport Package:Standard Export Package
- Specification:PGW
- Trademark:YUSHENG
- Origin:Jiangsu Province, China
- HS Code:8477800000
- Production Capacity:50sets,Year
Description
Technical Parameters1 Outer Dimension of Machine(mm) About 3100×2440×2300 2 Pipe Outer Diameter 50-160mm 3 Heating Method Ceramic infrared heating 4 Heating Power 18kw 5 Heating station 2 6 cooling method air coooling and water cooling 7 total power of hydraulic system 5.5kw 8 socketing station 2 9 socket type U type and R type 10 hydrailic oil 46# wear resistance hydraulic oil 11 Max heating temperature 300centigrade 12 Air pressure 0.4-0.6Mpa 13 Water pressire 0.2-0.3Mpa 14 Pipe rotate motor power 0.37kw 15 pipe unload motor power 0.18kw 16 bending speed Φ110×2.0mm 80seconds/pipe
