High Speed Film Blowing Machine (CE)
Ruian Fangtai Machinery Co., Ltd.- Type：PE Film Blowing Machine
- Raw Material：PE
- Maximum Folding Width of Film：1500mm
- Screw Diameter：70mm
- Automation：Automatic
- Computerized：Computerized
Base Info
- Model NO.：SJ-C75, SJ-C 90, SJ-C105, SJ-C120
- Machine Weight：4T
- Certification：CE
- Material：PE
- Transport Package：Wooden Case, Wooden Block, in Nude
- Specification：standard process
- Trademark：Fangtai
- Origin：ruian, china
- HS Code：84778000
- Production Capacity：1 set, month
Description
Model
SJ-C75
SJ-C90
SJ-C105
SJ-C120
Screw Diameter
75mm
90mm
105mm
120mm
Screw Ratio(L/D)
28:1
28:1
28:1
28:1
Screw Speed
10-100r/min
10-100r/min
10-100r/min
10-100r/min
Power of Main Motor
30-37Kw
37-45Kw
54-70Kw
70-90Kw
Main Output
120kg/h
160kg/h
190kg/h
220kg/h
Max. Folding
Width of Film
1500mm
2000mm
2500mm
3000mm
Single-sided
Thickness of Film
0.01-0.10mm
0.01-0.10mm
0.01-0.10mm
0.01-0.10mm
Total Power
46Kw
60Kw
78Kw
95Kw
Weight of Machine
4T
8T
10T
12T
Overall Dimensions
5200×2800×6000
6200×3400×8000
6200×4000×9000
6800×4500×10000
