• Model NO.：XJY-SJ950,420
• Customized：Customized
• Condition：New
• Machine Condition：New
• Application：Sheet
• Plastic Processed：PVC
• Screw Design：Double-Screw
• Automatic Grade：Fully Automatic
• Brand Name：Lanhang
• Voltage：380V
• Power(W)：220000
• Dimension(L*W*H)：2.7X2.5X3.0 M
• Weight：50 T
• Transport Package：Wood Pallet & Film Wrap (Pet Sheet Making Machine)
• Specification：CE, SGS, lAF, CNAS, ISO9001
• Trademark：LANHANG
• Origin：Jiangsu, China
• HS Code：8477
• Production Capacity：100 Set,Sets Per Year

Model
XJY-ZS750/300
XJY-ZS950/420
Diameter of Front Screw (mm)
300
416
Diameter of Rear Screw (mm)
740
936
Rotating Speed of Screw (r/min)
3-26
3-28
Power of Screw Motor (Kw)
DC132
DC220
Diameter of Roller (mm)
Φ400
Φ500
Working Length of Roller (mm)
1000
1100
Power of Roller Motor (Kw)
132
220
Linear Speed of Roller (m/min)
3.5-35
4-40
Sheet Width (mm)
700
800
Sheet Thickness (mm)
5-12
2-12
Capacity (Kg/h)
450-9000
9000-11000
Dimension (m)
2.5x2.3x2.7
2.7x2.5x3.0
Weight (Kg)
30
50

Outline of the Kneader Sheet Preformer
The Kneader sheet preformer was designed to manufacture rubber sheets on a fully automatic basis. This uniquely designed sheet preformer consists of two sections, a twin taper screw feeder and a roller die unit. The feeder section has a large volume hopper, which is capable of handling multiple batches directly from a mixer. The twin taper screws "bite" and feed the rubber compound into a horizontal roller die for automatic and continuous sheeting, while large volume cooling jackets in the feeder and roller die section imparts effective cooling to the rubber compound. The unit function as replacing mixing mill, and it reduces cost and improves working efficient.

Features of PET Sheet Making Machine
1. Automated sheet production
2. Consistent material feed to rolls
3. Excellent sheet cooling capabilities
4. Produce sheet with less energy costs
5. Self cleaning - no residual material left in feeder section
6. Reduced wear (no feed screw to casing contact)
7. Improves compound uniformity



Packaging & Shipping
Wood Pallet & Film Wrap ( PET Sheet Making Machine )

Our Services
PVC Sheet Making Machine
1. One year warranty
2. Engineers available to service machinery overseas (installation, debugging, commissioning and maintenance.)
3. Overseas service center available (in Europe, Japan, Dubai, etc.)
4. Life-long technical support
