• Model NO.：SGK-630
• HS Code：84772090
• Production Capacity：20set,Year

Mechanical parts:Parameter:Rang of pipe bellingØ315-630Rang of pipe thickness7.7-24.1mmQTY. of heating oven2QTY. of belling station1Length of belling pipe4-6mChilling water0.4 m³/hCalibration(cooling) typeWater and Air coolingBelling control Automatic, manual Heating controlAdjustablePipe tipping Automatic Pneumatic pressure0.6-0.8Mpa,adjustableHydraulic oil pump modelVPV1-140-40Rated pressure of hydraulic oil6.3Mpa, the working pressure is adjustableBelling Socketing Tools material 40Cr, rigidity HV800-900, chrome plate surface
Estimated Plant ParametersCapacity(kg/h)Power Installed(kw)Required()ManpowerCompressed(m³/min)Water
Supply(m³/min)30050035040.6350062046060.64100070050060.65
Machine List Components of Pet Bottle Washing Line:
Label Remover machine---Sorting system---PET Crusher machine---Flakes Floating washing tank---Hot Washing system,---Frication washing system---dewatering  machinery and fin dust label separator machine---hot air drying system and the Packing system



Beier Machinery film washing lines can assure a precise and efficient decontamination of the post-consumer film with both cold and hot washing systems, adopting the most efficient recycling technologies. The final target of post-consumer film recycling is to obtain the highest valorization of a very poor starting product, deriving mostly from waste collection.Beier Machinery film washing line can properly treat any contaminated post consumer film and bring the final output washed flakes back to be reused (alone or blended with other materials) even in new film blowing applications.

Our certification
